Airtac SDA Ultra Thin Cylinder SDA80X50
2. Features riveted structure between cylinder body/rear cover and piston/piston rod, ensuring compactness and reliability;
3. Cylinder bore undergoes roller burnishing followed by hard anodizing treatment for superior wear resistance and durability;
4. Asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir functionality;
5. Space-saving design optimizes installation footprint;
6. Peripheral T-slots for magnetic sensors enable convenient switch mounting;
7. Multiple model variations available across comprehensive specifications.
Category: Slim Cylinders , Brand: AirTAC , Series: SDA
AirTAC SDA80X50 Ultra-Thin Cylinder Specifications
- Model: SDA80X50
- Bore size: 80mm
- Stroke: 50mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Temperature range: -20℃ to 80℃
- Cushioning type: Fixed rubber buffer
- Port size: M5x0.8 (G1/8 optional)
- Mounting type: Basic (Standard) / MF1 front flange / LB5 side lug
- Rod end type: Female thread (M10x1.25)
- Seal material: NBR (Nitrile) standard / Optional FKM (Fluorocarbon)
- Weight: 1.65 kg (bare cylinder) / 1.82 kg (with accessories)
- Dimensions:
- Length: 160mm (retracted) / 210mm (extended)
- Width: 95mm (including mounting holes)
- Height: 80mm (cylinder body)
- Protection rating: IP54 (standard) / IP67 (optional wiper upgrade)
- Lubrication: Pre-lubricated (maintenance-free for 2000km operation)
Ultra-compact profile cylinder with high moment resistance, featuring anodized aluminum construction for lightweight durability. The SDA series incorporates a unique anti-rotation mechanism and precision honed tube for smooth operation. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality standards.
- High-density robotic assembly cells
- Semiconductor wafer handling systems
- Medical device positioning mechanisms
- Packaging machine clamp actuators
- Automated test equipment (ATE) fixtures
Installation note:
Use precision alignment jigs during mounting. Maximum allowable lateral load:
15N at full extension. For vertical installations, always install rod end downward
to prevent piston rod contamination.
| Property | Property Value |
|---|---|
| sku | SDA80X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <50mm> |
