Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X10-10SB
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X10-10SB Adjustable Slim Cylinder Specifications
- Series: SDAJ12~25 (12mm/16mm/20mm/25mm bore sizes)
- Model: SDAJ12X10-10SB
- Type: Double-acting adjustable cushion cylinder
- Bore size: 12mm
- Stroke: 10mm (customizable 5-100mm)
- Operating pressure: 0.1-0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Foot-mounted (MF1) standard
- Port size: M5x0.8 (1/8" NPT optional)
- Material: Aluminum alloy cylinder tube, chrome-plated piston rod
- Seal material: NBR
- Protection rating: IP40
- Weight: 0.15kg (approx. 5.3oz)
- Dimensions: 50mm(L) × 34mm(W) × 16mm(H) (1.97"×1.34"×0.63")
Ultra-slim profile pneumatic cylinder with 16mm height profile, designed for space-constrained automation systems. Features dual adjustable cushions for precise end-position control and reduced impact noise. The anodized aluminum construction ensures corrosion resistance, while the chrome-plated piston rod provides smooth operation. Requires 5μm filtered compressed air with lubrication (ISO VG32 recommended).
- PCB handling robots in electronics manufacturing
- Medical device positioning mechanisms
- Packaging machine clamping units
- Semiconductor wafer processing equipment
- Precision valve actuation systems
Installation tip:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components for heat dissipation.
For vertical mounting, use lock nuts on piston rod threads (M5×0.8 standard). Lubricate every 500,000 cycles in normal operation.
| Property | Property Value |
|---|---|
| sku | SDAJ12X10-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
