Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-10SB
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X15-10SB Adjustable Slim Cylinder Specifications
- Series: SDAJ12~25 (12mm bore size)
- Full model: SDAJ12X15-10SB
- Bore size: 12mm
- Stroke: 15mm (adjustable with ±0.5mm precision)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable air cushion (dual-side)
- Mounting type: Basic foot mounting (10SB code)
- Port size: M5x0.8 (dual ports)
- Piston speed: 50–800 mm/s
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR rubber (oil-resistant)
- Weight: 0.15 kg (excluding accessories)
- Dimensions:
- Length: 53mm (stroke 15mm + end caps)
- Width: 20mm (cylinder body)
- Height: 32mm (including mounting foot)
Precision-engineered ultra-slim cylinder featuring dual adjustable cushions for vibration-free stopping. The compact 12mm bore design achieves 32% space savings vs standard cylinders. Integrated mounting slots enable tool-free installation. Includes wear-resistant rod guide for extended service life.
- PCB handling robots requiring micron-level positioning
- Medical device actuation mechanisms
- Semiconductor wafer clamping systems
- Automated optical inspection (AOI) equipment
- Miniature part sorting/pick-and-place machines
Maintenance tip: Lubricate through air supply (ISO VG32 recommended).
Avoid lateral loads exceeding 3N·m. For vertical mounting,
reduce operating pressure by 20% when handling downward thrust.
| Property | Property Value |
|---|---|
| sku | SDAJ12X15-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
