Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20
$26.27
Regular price
$33.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ12X20-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The SDAJ12~25 Adjustable Ultra-Thin Cylinder Series by AIRTAC
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
Installation tip:
Use locknuts (not included) on adjustment screws after setting stroke length.
Maintain 0.5mm minimum clearance between cylinder body and adjacent components
for heat dissipation. Lubricate guide shafts every 500,000 cycles with ISO VG32 hydraulic oil.
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X20-20 Adjustable Slim Cylinder Specifications
- Series: SDAJ12~25 (Compact Adjustable Series)
- Model: SDAJ12X20-20
- Bore size: 12mm
- Stroke: 20mm (Adjustable)
- Mounting type: Dual axial mounting holes
- Operating pressure: 0.05~0.7 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable stopper
- Port size: M5x0.8 (Two 4mm push-in fittings included)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR seals (Oil-resistant)
- Weight: 0.23kg (Without accessories)
- Dimensions: 67mm(L) × 20mm(W) × 32mm(H)
- Stroke tolerance: ±0.5mm
- Protection rating: IP54 (Standard dust/moisture resistance)
Ultra-slim profile cylinder (only 20mm width) with precision stroke adjustment mechanism. Features dual-position locking screws for fixed stroke settings and anti-rotation piston rod. Pre-lubricated for maintenance-free operation up to 2,000km travel distance. Compatible with ISO 6432 mounting accessories.
Ideal for:
- PCB board clamping in SMT machines
- Precision door interlocks in semiconductor equipment
- Label positioning in high-speed packaging lines
- Camera module actuation in optical inspection systems
- Medical device linear motion (e.g., sample tray positioning)
Installation tip:
Use locknuts (not included) on adjustment screws after setting stroke length.
Maintain 0.5mm minimum clearance between cylinder body and adjacent components
for heat dissipation. Lubricate guide shafts every 500,000 cycles with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SDAJ12X20-20 |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
