Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X25-20SB
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X25-20SB Adjustable Ultra-Thin Cylinder Specifications
- Model: SDAJ12X25-20SB
- Series: SDAJ12~25 (12mm bore size)
- Stroke: 25mm (adjustable via built-in stroke adjustment mechanism)
- Operating pressure: 0.05~0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable cushion screw
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Mounting type: Basic foot mounting (20SB code)
- Material:
- Cylinder tube: Aluminum alloy hard anodized
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 180g ±5% (without accessories)
- Dimensions:
- Total length (retracted): 70mm
- Width: 34mm
- Height: 34mm
- Stroke tolerance: ±1.5mm
- Protection rating: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (DOP anti-wear oil)
Ultra-compact profile cylinder with space-saving 34×34mm cross-section, featuring dual-side adjustable stroke mechanism (via rotating end caps). Precision-engineered for high-speed applications requiring ≤1.5m/s piston speed. Integrated magnetic sensor groove (T-slot) for position detection compatibility. Optional auto switch models available.
- PCB handling robots in electronics assembly
- Medical device positioning mechanisms
- Packaging machine clamp actuators
- Semiconductor wafer transfer systems
- Cleanroom automation equipment
Installation note:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components.
For vertical mounting, use anti-vibration pads (AVP-12 kit recommended).
Lubricate every 500km stroke operation in dusty environments.
| Property | Property Value |
|---|---|
| sku | SDAJ12X25-20SB |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
