Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X10-10
2、Features riveted connection between cylinder body/rear cap and piston/piston rod for enhanced structural integrity;
3、Precision roller burnishing followed by hard anodizing treatment on inner bore surface ensures superior wear resistance and durability;
4、Unique custom bi-directional sealing profile with integrated oil reservoir optimizes compactness and lubrication retention;
5、Space-saving design minimizes installation footprint while maintaining performance;
6、Integrated sensor grooves along cylinder periphery facilitate effortless sensor mounting;
7、Available in multiple mounting configurations for flexible system integration.
Category: Slim Cylinders , Brand: AirTAC , Series: SDAJ32~40 Adjustable Ultra-Compact Cylinders
AirTAC SDAJ32X10-10 Adjustable Slim Cylinder Specifications
- Series: SDAJ32~40 Ultra-Slim Series
- Bore size: 32mm
- Stroke: 10mm (adjustable with built-in stopper)
- Mounting type: Basic foot/Flange options available
- Operating pressure: 0.1~0.9 MPa
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (1/8" NPT optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal material: NBR/PU combination
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
- Weight: 0.68kg ±2%
- Dimensions: 70mm(L) × 32mm(W) × 40mm(H)
- Rod end thread: M6×1.0 internal thread
- Repeat accuracy: ±0.2mm
- Max theoretical thrust: 231N@0.6MPa
Ultra-compact profile (40mm height) cylinder with space-saving design for confined installations. Features dual adjustable stroke mechanism with visual position indicator slots. Corrosion-resistant construction with IP54 protection rating. Ideal for precision push-pull operations requiring controlled force and minimal footprint.
- PCB press-fitting mechanisms in electronics assembly
- Medical device actuation systems
- Automated door locking mechanisms
- Packaging machine clamping units
- Food processing conveyor gate controls
Installation tip:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use anti-drop lock nuts (spec code: ADLN-6).
Lubricate every 5,000km stroke operation.
| Property | Property Value |
|---|---|
| sku | SDAJ32X10-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <10mm> |
