Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10SB
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50~63 Adjustable Compact Cylinder SDAJ50X10-10SB Specifications
- Model Series: SDAJ50~63 (50mm/63mm bore sizes)
- Full Model: SDAJ50X10-10SB
- Bore Size: 50mm
- Stroke: 10mm (adjustable stroke type)
- Operating Pressure: 0.15–0.8 MPa
- Port Size: M5x0.8 (1/8" NPT optional)
- Cushioning: Adjustable air cushion (both ends)
- Piston Speed: 50–800 mm/s
- Ambient Temperature: -20℃ to 80℃
- Mounting Type: Standard foot/axial mounting holes
- Rod Material: Stainless steel (SUS304)
- Body Material: Anodized aluminum alloy
- Seal Material: NBR (nitrile rubber)
- Weight: 1.2kg (with accessories)
- Dimensions:
- Length: 98mm (min. compact length)
- Width: 64mm (mounting base span)
- Height: 50mm (including rod end)
- ISO Standard: Compliant with ISO 6432
Ultra-slim profile cylinder (40% thinner than standard models) with precision stroke adjustment via hex wrench. Features dual anti-rotation guide rods for enhanced lateral stability. Integrated cushioning adjustment screws allow fine-tuning of end-position damping (0–5mm adjustable buffer stroke). Pre-lubricated for maintenance-free operation.
- High-density PCB component insertion machines
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging systems
- Automated microscope stage positioning
- Cleanroom-compatible automation equipment
Installation tip:
For vertical mounting, use counterbalance valves when handling suspended loads.
Lubricate rod weekly with ISO VG32 hydraulic oil in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | SDAJ50X10-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <10mm> |
