Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-100SB
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-100SB Adjustable Slim Cylinder Specifications
- Series: SDAJ50~63 Ultra-Slim Cylinder Line
- Model: SDAJ50X100-100SB
- Bore size: 50mm (2.0")
- Stroke: 100mm (adjustable via external stopper)
- Operating pressure: 0.05~0.8 MPa
- Temperature range: -20℃ to 80℃
- Buffer type: External adjustable rubber cushion
- Mounting style: Standard foot-mounted (ISO 15552 compatible)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal type: NBR seals with wear-resistant ring
- Built-in sensors: 2x magnetic reed switches (100SB suffix)
- Weight: 1.2kg (excluding accessories)
- Dimensions:
- Body length: 140mm (non-extended)
- Total stroke length: 240mm (fully extended)
- Width: 63mm (mounting foot span)
- Height: 50mm (barrel diameter)
Industry-leading compact cylinder with 19mm reduced height profile (40% slimmer than standard models). Features dual-position sensor slots for precise position feedback and maintenance-free operation. The adjustable cushioning mechanism minimizes end-impact noise (68dB max) while maintaining 98% energy efficiency. Includes corrosion-resistant coating for harsh environments.
- PCB handling robots requiring precise vertical motion
- Pharmaceutical blister packaging machines
- Automated test equipment with space constraints
- Cleanroom-compatible medical devices
- High-speed sorting systems (up to 5 cycles/sec)
Installation tip:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
Lubricate with ISO VG32 hydraulic oil if used below -10℃. Replace seals every
2 million cycles in high-speed applications.
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-100SB |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
