Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-10SB
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-10SB Adjustable Slim Cylinder Specifications
- Series: SDAJ50~63 (50mm/63mm bore sizes)
- Model: SDAJ50X100-10SB
- Bore size: 50mm
- Stroke: 100mm (adjustable via built-in stroke adjustment mechanism)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Mounting type: Front flange with 4xM5 threaded holes (ISO 15552 standard)
- Port size: M5x0.8 (standard) / 1/8" NPT optional
- Piston rod material: Hard chrome-plated SUS304
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber) with wear-resistant ring
- Built-in sensor: Magnet-embedded piston (compatible with inductive sensors)
- Weight: 1.45 kg (bare cylinder without accessories)
- Dimensions (L×W×H):
- Retracted length: 164mm
- Extended length: 264mm
- Width (mounting flange): 63mm
- Height (including rod): 74mm
Ultra-slim profile cylinder (22% thinner than standard models) with precision stroke adjustment capability. Features double-sealed piston design for leak-free operation and IP67 protection rating. Integrated mounting grooves allow direct sensor installation without brackets. Optional auto switch models available (specify -D suffix).
- High-density automation cells with space constraints
- Precision clamping fixtures in CNC machining centers
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Cleanroom-compatible automation systems
Installation tip:
For vertical mounting, use counterbalance valves when handling loads >5kg.
Lubricate with ISO VG32 hydraulic oil during assembly. Avoid side load forces
exceeding 30N to prevent rod bearing wear.
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
