Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-20
$88.37
Regular price
$95.87
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ50X100-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
Installation tip: Use alignment jigs during mounting to prevent side load. For vertical installations exceeding 45° angle, install an air pressure maintenance valve. Lubricate with ISO VG32 turbine oil before initial operation.
Cushion adjustment procedure: 1) Loosen lock nut 2) Turn adjuster clockwise to strengthen cushioning 3) Test at 80% maximum speed 4) Secure after 3 operation cycles
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-20 Adjustable Thin Cylinder Specifications
- Series: SDAJ50~63 Ultra-Slim Cylinder Family
- Model: SDAJ50X100-20
- Bore size: 50mm (2")
- Stroke: 100mm ±0.5mm tolerance
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Piston speed: 50–800 mm/s (lubricated)
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (optional double-axis MF1/MB1)
- Port size: M5x0.8 (standard), G1/8 optional
- Ambient temperature: -20℃ to 80℃ (NBR seals)
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel (H5 precision)
- Weight: 1.48kg (bare cylinder), 1.68kg with accessories
- Dimensions: 200mm(L) × 63mm(W) × 63mm(H)
- Protection class: IP40 (standard), IP67 optional
- ISO standard: 6432 compliant
Ultra-compact profile (23% thinner than standard cylinders) with precision stroke adjustment via hexagonal wrench. Features dual-position sensor slots (M5 threaded) for magnetic switch installation. The anodized barrel resists corrosion in humid environments, while the double-seal design prevents leakage at low pressure operations.
Typical Applications:
- PCB handling robots requiring slim actuators
- Pharmaceutical tablet pressing mechanisms
- Semiconductor wafer transfer systems
- Vertical lift gates in cleanroom environments
- Precision clamping in CNC tool changers
Installation tip: Use alignment jigs during mounting to prevent side load. For vertical installations exceeding 45° angle, install an air pressure maintenance valve. Lubricate with ISO VG32 turbine oil before initial operation.
Cushion adjustment procedure: 1) Loosen lock nut 2) Turn adjuster clockwise to strengthen cushioning 3) Test at 80% maximum speed 4) Secure after 3 operation cycles
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-20 |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
