Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-20S
$101.19
Regular price
$108.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ50X100-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
Installation Tip:
Use anti-rotation brackets (Order code: SDAJ-ARB50) when mounting vertically.
Lubricate with ISO VG32 turbine oil if operating below 0.5m/s. Avoid side loads exceeding 15N.
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-20S Adjustable Compact Cylinder Specifications
- Series: SDAJ50~63 Ultra-Thin Cylinder Family
- Full Model: SDAJ50X100-20S
- Bore Size: 50mm (Standard SDAJ series: 50/63mm options)
- Stroke: 100mm (Adjustable via built-in stroke limiter)
- Operating Pressure: 0.05~0.9 MPa
- Temperature Range: -20℃ to 80℃ (Dry air required below 0℃)
- Port Size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Buffer Type: Adjustable rubber cushion (Both ends)
- Mounting Style: 20mm center hole (ISO 15552 accessory compatible)
- Rod Material: Stainless steel SUS304
- Body Material: Anodized aluminum alloy
- Seal Material: NBR + PU combination
- Weight: 0.82kg ±5% (Without accessories)
- Dimensions: 200mm(L) × 50mm(W) × 63mm(H) (At full extension)
- Repeat Accuracy: ±0.1mm (Under 0.5MPa)
- Max Speed: 500mm/s (With proper cushion adjustment)
- ISO Certification: 6431/15552 compliant
Ultra-flat cylinder (Only 63mm height) with space-saving design for robotics and precision mechanisms. Features dual-axis adjustability through rotating locknuts (15mm adjustment range). Integrated T-slot mounting enables 360° accessory attachment. IP54-rated for dust/moisture resistance.
Industrial Applications:
- PCB handling robots in electronics manufacturing
- Glass panel pressing mechanisms
- Pharmaceutical blister packaging machines
- Automated optical inspection (AOI) equipment
- Wafer transfer systems in semiconductor fabs
Installation Tip:
Use anti-rotation brackets (Order code: SDAJ-ARB50) when mounting vertically.
Lubricate with ISO VG32 turbine oil if operating below 0.5m/s. Avoid side loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
