Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-20SB
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-20SB Adjustable Ultra-Thin Cylinder Specifications
- Series: SDAJ50~63 Compact Series
- Model: SDAJ50X100-20SB
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable via built-in stroke adjuster)
- Mounting type: Front flange with side mounting holes (Standard ISO 15552 foot mounting compatible)
- Operating pressure: 0.05~0.8 MPa
- Cushioning: Adjustable rubber bumper (dual-side)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Piston rod material: Hard chrome-plated stainless steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR seals with wear-resistant ring
- Ambient temperature: -20℃ to +80℃
- Weight: 1.45 kg ±2% (without accessories)
- Dimensions (L×W×H):
- Retracted length: 162 mm
- Extended length: 262 mm
- Body width: 63 mm
- Mounting height: 50 mm
- Rod end: Female thread M10x1.25
- Lubrication: Pre-lubricated (Oil-free operation possible)
Ultra-slim profile cylinder (23% thinner than standard models) with integrated guide rails for enhanced moment resistance. Features dual-position proximity sensor slots (inductive sensor compatible) and anodized corrosion-resistant surfaces. The 20SB variant includes shock-absorbing end caps and reinforced rod bearings for high-cycle applications.
- PCB handling robots in electronics manufacturing
- Clamping mechanisms in CNC tool changers
- Vertical lift gates in automated warehouse systems
- Precision paper feeding in digital printers
- Medical device positioning stages
Installation tip:
Maintain 0.5-1mm clearance between cylinder body and machine frame for thermal expansion.
Use anti-vibration washers when mounting on moving platforms. Lubricate guide rails with ISO VG32 hydraulic oil every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-20SB |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
