Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40SB
$101.19
Regular price
$108.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ50X100-40SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
Installation tip:
Use locknuts on both sides of adjustment mechanism for vibration resistance.
Maximum side load capacity: 15N at full extension. Lubricate rod with ISO VG32
pneumatic oil monthly in high-cycle applications.
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-40SB Adjustable Slim Cylinder Specifications
- Series: SDAJ50~63 (Compact Adjustable Series)
- Model: SDAJ50X100-40SB
- Bore size: 50mm
- Stroke: 100mm (adjustable)
- Adjustment range: 0-100mm via mechanical stopper
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (front/rear)
- Mounting type: Foot mounting (standard)
- Port size: M5x0.8 (Rc1/8 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 80℃
- Weight: 1.85kg ±5%
- Dimensions (L×W×H): 200×63×63mm (full extension)
- Retract length: 100mm (minimum compact length)
- Rod thread: M10×1.25
- Protection rating: IP54 (standard)
Ultra-slim profile cylinder (40% thinner than standard models) with precision stroke adjustment mechanism. Features dual-position locking nuts for fine-tuning stroke length during operation. Anti-rotation design maintains tooling alignment. Integrated cushioning adjustment screws allow dynamic deceleration control.
Typical Applications:
- PCB handling robots requiring precise positioning
- Space-constrained medical device actuators
- Semiconductor wafer clamping mechanisms
- Automated packaging machine ejectors
- Photovoltaic panel alignment systems
Installation tip:
Use locknuts on both sides of adjustment mechanism for vibration resistance.
Maximum side load capacity: 15N at full extension. Lubricate rod with ISO VG32
pneumatic oil monthly in high-cycle applications.
Sensor Options:
- Magnetic reed switch (D-A93 compatible)
- Non-contact Hall effect sensor (PNP/NPN output)
- Stroke-end detection accuracy: ±1mm
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-40SB |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
