Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50SB
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-50SB Adjustable Ultra-Thin Cylinder Specifications
- Series: SDAJ50~63 Compact Series
- Model: SDAJ50X100-50SB
- Bore size: 50mm
- Stroke: 100mm (±0.5mm adjustability)
- Mounting type: Basic non-magnetic switch model
- Operating pressure: 0.15-1.0 MPa
- Cushion type: Fixed rubber + adjustable cushioning
- Adjustable stroke function: ±0.5mm via external hex screw
- Port size: M5x0.8 (Rc1/8 optional)
- Piston rod thread: M10x1.25
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: 0.92kg (excluding accessories)
- Dimensions:
- Body height: 63mm (ultra-flat design)
- Total length (retracted): 172mm
- Total length (extended): 272mm
- Mounting base width: 50mm
- Action type: Double-acting
- Max theoretical thrust: 157N @0.5MPa
- Air consumption: 6.3L/stroke @0.5MPa
- Repeat positioning accuracy: ±0.2mm
This ultra-compact cylinder features a 30% slimmer profile than standard models while maintaining high rigidity. The integrated stroke adjustment mechanism allows fine-tuning without disassembly, with anti-rotation piston rod stabilization. Anodized aluminum construction with chrome-plated rod resists corrosion in humid environments.
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC tool changers
- Compact positioning in medical device actuators
- High-density packaging line pushers
- Cleanroom-compatible automation systems
Installation note:
Maintain parallel alignment during mounting - maximum allowable angular error ≤0.5°. Use locknuts for stroke adjustment screws after calibration. Lubricate with ISO VG32 turbine oil for optimal seal performance.
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-50SB |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
