Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10SB
2. Riveted construction between cylinder body & rear cover, piston & piston rod ensures compactness and reliability;
3. Cylinder bore undergoes roller burnishing followed by hard anodizing treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston features compact dimensions and incorporates an integrated oil reservoir for lubrication retention;
5. Space-optimized design maximizes installation efficiency in confined spaces;
6. Perimeter sensor groove design facilitates straightforward sensor mounting;
7. Available in multiple configurations to accommodate diverse application requirements.
Category: Compact Cylinders | Brand: AIRTAC | Series: SDAJ80~100
AirTAC SDAJ Series Adjustable Ultra-Thin Cylinder SDAJ100X10-10SB Specifications
- Model: SDAJ100X10-10SB (SDAJ80~100 series)
- Type: Double-acting adjustable stroke ultra-thin cylinder
- Bore size: Ø100 mm
- Stroke: 10 mm (adjustable range: 0-10mm)
- Operating pressure: 0.05~1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer + air cushion
- Mounting style: Basic type (SW100-10SB mounting brackets)
- Port size: Rc1/4 (G1/4 optional)
- Seal material: Heat-resistant NBR
- Repeat positioning accuracy: ±0.2 mm
- Max piston speed: 500 mm/s
- Protection rating: IP40 (dust-proof)
- Weight: 2.5 kg (with standard accessories)
- Dimensions:
- Length: 135 mm (cylinder body) + stroke
- Width: 100 mm (square housing)
- Height: 42 mm (ultra-thin profile)
Engineered for space-constrained automation systems, the SDAJ100X10-10SB features a 42mm ultra-slim profile - 30% thinner than standard cylinders. Its dual-axis adjustable stroke mechanism allows micron-level positioning through the integrated locknut system. The hardened anodized aluminum body ensures wear resistance in high-cycle applications (up to 10 million cycles). Includes anti-rotation guide rods for precise linear motion.
- PCB handling robots in electronics manufacturing
- Glass panel pressing/polishing equipment
- Pharmaceutical tablet compression machines
- Precision clamping in CNC tool changers
- Solar cell lamination systems
Installation tip:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 50N.
For vertical mounting, reduce operating speed by 20% to prevent piston rod sag.
Stroke adjustment requires 2.5mm hex key (not included).
| Property | Property Value |
|---|---|
| sku | SDAJ100X10-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
