Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10SB
2. Riveted construction between cylinder body & rear cover, piston & piston rod ensures compactness and reliability;
3. Cylinder bore undergoes roller burnishing followed by hard anodizing treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston features compact dimensions and incorporates an integrated oil reservoir for lubrication retention;
5. Space-optimized design maximizes installation efficiency in confined spaces;
6. Perimeter sensor groove design facilitates straightforward sensor mounting;
7. Available in multiple configurations to accommodate diverse application requirements.
Category: Compact Cylinders | Brand: AIRTAC | Series: SDAJ80~100
AirTAC SDAJ80~100 Adjustable Ultra-Thin Cylinder SDAJ100X100-10SB Specifications
- Model: SDAJ100X100-10SB
- Series: SDAJ (Ultra-slim adjustable stroke)
- Bore size: 100mm
- Stroke: 100mm (adjustable from 0-100mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: G1/2 (ISO228 standard)
- Cushioning: Adjustable rubber buffer
- Mounting type: Basic (no flange)
- Material: Aluminum alloy body, CRCO piston rod
- Weight: 4.2kg ±2%
- Dimensions (L×W×H): 200mm × 100mm × 125mm (extended length)
- Stroke adjustment: Mechanical stopper with locknut
- Seal material: HNBR (Hydrogenated Nitrile)
- Protection rating: IP40 (dust protected)
Ultra-compact profile cylinder (only 100mm width) with field-adjustable stroke mechanism, ideal for space-constrained automation solutions. Features precision-machined guide grooves for stable linear motion and anti-rotation performance. Optional magnetic version available for position sensing.
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC tool changers
- Material positioning in packaging lines
- Medical device assembly systems
- Solar panel production equipment
Installation note:
Maximum lateral load 150N. Lubricate piston rod monthly with ISO VG32 turbine oil.
Avoid side impact during stroke adjustment - loosen locknut before positioning stopper.
| Property | Property Value |
|---|---|
| sku | SDAJ100X100-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
