Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-40SB
2. Riveted construction between cylinder body & rear cover, piston & piston rod ensures compactness and reliability;
3. Cylinder bore undergoes roller burnishing followed by hard anodizing treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston features compact dimensions and incorporates an integrated oil reservoir for lubrication retention;
5. Space-optimized design maximizes installation efficiency in confined spaces;
6. Perimeter sensor groove design facilitates straightforward sensor mounting;
7. Available in multiple configurations to accommodate diverse application requirements.
Category: Compact Cylinders | Brand: AIRTAC | Series: SDAJ80~100
AirTAC SDAJ100X100-40SB Adjustable Ultra-Slim Cylinder Specifications
- Model series: SDAJ80~100
- Specific model: SDAJ100X100-40SB
- Bore size: 100mm
- Stroke: 100mm (adjustable through external stopper)
- Operating pressure: 0.05~0.8 MPa
- Port size: M5×0.8 (standard) or NPT1/8 (optional)
- Piston speed: 50~700mm/s
- Cushion type: Fixed rubber bumper + adjustable air cushion
- Body material: Aluminum alloy (anodized surface)
- Rod material: Chrome-plated stainless steel
- Seal material: NBR (nitrile rubber)
- Ambient temperature: -20℃ to +80℃
- Weight: 2.4kg (excluding accessories)
- Dimensions:
- Length: 215mm (min) ~ 315mm (max extended)
- Width: 126mm (mounting face)
- Height: 42mm (profile thickness)
- Mounting type: Basic female thread (other options: ISO/VDMA standard)
- Lubrication: Pre-lubricated (relubrication interval: 3,000km stroke)
Ultra-low profile cylinder featuring a 20% slimmer profile than standard models, designed for space-constrained automation systems. The dual-cushion system combines fixed mechanical buffering with adjustable pneumatic damping for precise end-position control. Includes auto-switch grooves for sensor mounting (inductive type recommended).
- PCB handling robots in electronics manufacturing
- Clamping mechanisms in CNC tool changers
- Vertical lift systems in pharmaceutical packaging
- Precision alignment stages in optical equipment
- Palletizing systems with tight vertical clearance
Installation note:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components to prevent thermal expansion interference. For vertical mounting, use rod-down orientation to prevent piston drift.
| Property | Property Value |
|---|---|
| sku | SDAJ100X100-40SB |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
