Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-50SB
2. Riveted construction between cylinder body & rear cover, piston & piston rod ensures compactness and reliability;
3. Cylinder bore undergoes roller burnishing followed by hard anodizing treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston features compact dimensions and incorporates an integrated oil reservoir for lubrication retention;
5. Space-optimized design maximizes installation efficiency in confined spaces;
6. Perimeter sensor groove design facilitates straightforward sensor mounting;
7. Available in multiple configurations to accommodate diverse application requirements.
Category: Compact Cylinders | Brand: AIRTAC | Series: SDAJ80~100
AirTAC SDAJ80~100 Adjustable Ultra-Thin Cylinder SDAJ100X100-50SB Specifications
- Model Series: SDAJ80~100 (Standard Bore Size Range)
- Specific Model: SDAJ100X100-50SB
- Type: Double-acting adjustable stroke ultra-compact cylinder
- Bore Size: 100mm
- Stroke: Adjustable up to 100mm (50mm standard stroke with ±50mm adjustment range)
- Operating Pressure: 0.05~1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable stopper
- Mounting Style: Basic foot mounting (MF1) with multiple accessory options
- Port Size: M5x0.8 (Standard) / NPT1/8 optional
- Piston Rod Thread: M16x1.5
- Material:
- Cylinder Tube: Aluminum alloy hard anodized
- Piston Rod: Chrome-plated steel
- Seals: NBR (Nitrile rubber)
- Weight: 2.8kg (with standard accessories)
- Dimensions:
- Extended Length: 258mm (max stroke)
- Retracted Length: 158mm
- Body Height: 100mm
- Width: 100mm
- Mounting Foot Span: 120mm
Ultra-low profile cylinder with mechanical stroke adjustment mechanism, featuring 45% reduced height compared to standard cylinders. Precision-machined guide slots enable micrometer-grade positioning through the integrated stopper system. Corrosion-resistant construction with IP54 protection rating ensures reliability in harsh environments. Requires filtered air (≤40μm) with lubrication (ISO VG32 recommended).
- Precision clamping in CNC tool changers
- Vertical lift mechanisms for semiconductor wafer handling
- Space-constrained press-fit operations in automotive assembly
- Adjustable stops in packaging line diverters
- Medical device positioning systems requiring sterilization compatibility
Installation note:
Maintain parallel alignment within 0.2mm/m during mounting. For vertical installations,
use anti-rotation brackets (optional AR-100 accessory). Adjust stroke while depressurizing
the cylinder and lock adjustment screws with 2.5N·m torque.
| Property | Property Value |
|---|---|
| sku | SDAJ100X100-50SB |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
