Airtac SDR Pressure Regulator SDR10006L1
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
AirTAC SDR10006L1 Pressure Regulator Specifications
- Model: SDR10006L1
- Type: Precision pressure regulator with pressure gauge
- Port size: PT1/4 (G1/4 optional)
- Pressure adjustment range: 0.05–0.85 MPa
- Maximum flow rate: 1,500 L/min (ANR)
- Operating temperature: -5℃ to 60℃ (no freeze)
- Housing material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 0.62 kg ±3%
- Dimensions: 58mm(L) × 52mm(W) × 86mm(H)
- Pressure gauge range: 0–1.0 MPa (accuracy class 2.5)
- Venting method: Relief type (continuous exhaust)
- Mounting orientation: Any (vertical recommended)
High-sensitivity diaphragm regulator with integrated pressure gauge and lockable adjustment knob. Features anti-vibration structure and dust-resistant mechanism, optimized for stable pressure output in fluctuating flow conditions. Requires 5μm filtered air with ISO 8573-1:2010 Class 4.3.2 air quality.
- Pneumatic tool pressure stabilization
- Automated assembly line air circuits
- Semiconductor manufacturing equipment
- Textile machinery tension control systems
- Food packaging machine actuators
Maintenance tip:
Lubricate adjustment screw quarterly with ISO VG32 turbine oil.
Always depressurize system before turning knob counterclockwise
beyond zero scale to prevent diaphragm damage.
| Property | Property Value |
|---|---|
| sku | SDR10006L1 |
| Port Size | PT1/8 |
