Airtac SDR Pressure Regulator SDR10006LN
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
AirTAC SDR10006LN Precision Air Pressure Regulator Specifications
- Model: SDR10006LN
- Type: Pilot-operated pressure regulator with lockable knob
- Port size: PT1/4 (NPT1/4 optional)
- Pressure range: 0.05–0.85 MPa
- Maximum flow: 2000 L/min (ANR)
- Accuracy: ±0.02 MPa (at set pressure)
- Hysteresis: ≤0.02 MPa
- Body material: Anodized aluminum alloy
- Seal material: NBR/FKM (optional)
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Weight: 380g ±5%
- Dimensions: 82mm(L) × 48mm(W) × 105mm(H)
- Gauge port: M5 secondary port included
- Protection rating: IP54 (dust/water spray resistant)
High-sensitivity regulator featuring dual-chamber design for stable output under fluctuating input pressures. The chrome-plated adjustment knob includes a push-to-lock mechanism to prevent accidental setting changes. Integrated silencer reduces exhaust noise by 15dB compared to standard models.
- Precision pneumatic tool pressure control (e.g., torque-controlled assembly lines)
- Medical gas pressure regulation in dental chairs
- Packaging machine clamping force adjustment
- Laboratory pneumatic instrument calibration systems
- Semiconductor manufacturing cleanroom environments
Installation note:
Mount vertically with arrow direction matching airflow. Always install
a 5μm filter upstream. For pulsation-sensitive applications, add
a 1L reservoir between regulator and load. Avoid mounting near heat
sources exceeding 60℃.
| Property | Property Value |
|---|---|
| sku | SDR10006LN |
| Port Size | PT1/8 |
