Airtac SDR Pressure Regulator SDR100M51
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
AirTAC SDR100M51 Precision Pressure Regulator Specifications
- Model: SDR100M51 (Lockable Handle Type)
- Type: Pilot-operated pressure regulator with gauge port
- Port size: G1/4 (BSPP thread)
- Pressure range: 0.05–0.85 MPa
- Maximum flow: 1,200 NL/min
- Operating temperature: -5℃ to 60℃ (no freeze)
- Weight: 450g ±5%
- Dimensions: 100mm(H) × 50mm(W) × 85mm(D)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Pressure gauge range: 0–1.0 MPa (standard)
- Mounting orientation: Any (vertical recommended)
- Venting type: Internal exhaust with silencer
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating inlet pressures. The 360° rotatable gauge port allows flexible installation, while the lockable handle prevents accidental adjustment. Includes built-in filter (40μm) and silencer for noise reduction up to 5dB(A).
- Pneumatic conveyor tension control systems
- Injection molding machine air pressure management
- Automated assembly line tooling stations
- Semiconductor manufacturing equipment
- Packaging machine clamp force regulation
Installation note:
For optimal performance, install downstream of lubricator (F.R.L. sequence).
Drain condensate weekly through bottom vent. Use 2 wrenches during piping
to prevent body torsion - maximum tightening torque 15N·m.
| Property | Property Value |
|---|---|
| sku | SDR100M51 |
| Port Size | PTM5 |
