Airtac SDR Pressure Regulator SDR100M52
$19.30
Regular price
$26.80
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDR100M52
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Piston back-pressure structure with simple, compact design, cost-effective performance, and easy installation/operation;
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
Maintenance protocol:
Perform monthly diaphragm inspection and annual full calibration.
Always install downstream of filter units (recommended 5μm filtration).
Lubricator should be placed ≥300mm upstream if used.
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
AirTAC SDR100M52 Pressure Regulator Technical Details
- Model: SDR100M52
- Type: Precision air pressure regulator with gauge
- Port size: PT1/2 (G1/2 optional)
- Pressure range: 0.05–0.85 MPa
- Max flow capacity: 4500 L/min
- Operating medium: Filtered compressed air (lubricated/non-lubricated)
- Accuracy: ±0.02 MPa
- Hysteresis: ≤0.02 MPa
- Ambient temperature: -5℃ to 60℃
- Body material: Anodized aluminum alloy
- Diaphragm material: NBR reinforced rubber
- Weight: 510g ±5%
- Dimensions: 102mm(W) × 60mm(H) × 75mm(D)
- Mounting orientation: Vertical ±15°
- Pressure gauge range: 0–1.0 MPa (standard dial)
High-flow pressure stabilization device with integrated pressure gauge and tamper-resistant adjustment knob. Features dual-chamber design for stable output under fluctuating input pressures. Includes T-slot mounting for easy installation on DIN rails or flat surfaces.
Industrial Applications:
- Centralized pneumatic systems in automotive assembly lines
- Plastic injection molding machine pressure control
- CNC machine tool air circuit regulation
- Food packaging equipment pressure stabilization
- Semiconductor manufacturing cleanroom environments
Maintenance protocol:
Perform monthly diaphragm inspection and annual full calibration.
Always install downstream of filter units (recommended 5μm filtration).
Lubricator should be placed ≥300mm upstream if used.
| Property | Property Value |
|---|---|
| sku | SDR100M52 |
| Port Size | PTM5 |
