Airtac SDR Pressure Regulator SDR100M5L1
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
AirTAC SDR100M5L1 Pressure Regulator Technical Details
- Model: SDR100M5L1 (Manual Adjustment Type)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow capacity: 1,200 L/min
- Pressure gauge interface: Rc1/8
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃
- Weight: 450g ±5%
- Dimensions: 100mm(L) × 85mm(W) × 105mm(H)
- Pressure regulation accuracy: ±0.02 MPa
- Venting method: Non-bleed type
- Installation orientation: Any (360° rotatable gauge)
- Compliance: RoHS, ISO 9001:2015
Precision pressure regulator with integrated filter (40μm mesh) and lubricator retention structure. Features dual-chamber design for stable output under fluctuating loads and anti-vibration gauge mounting. The T-handle allows tool-free adjustment with ±180° rotation range and tactile torque feedback.
- Pneumatic conveyor systems in packaging lines
- Automated assembly tooling pressure control
- CNC machine air curtain regulation
- Semiconductor manufacturing equipment
- Industrial robot end-effector pressure management
Maintenance protocol:
Replace filter element every 2,000 operational hours. Use ISO VG32 turbine oil
for lubrication maintenance. Avoid downward-facing installation when handling
particulate-laden air streams.
| Property | Property Value |
|---|---|
| sku | SDR100M5L1 |
| Port Size | PTM5 |
