Airtac SDR Pressure Regulator SDR20008JN
2. Wide pressure regulation range including standard and low-pressure variants. Maintains stable output pressure, ideal for applications with moderate pressure requirements prioritizing cost-efficiency;
3. Unitized mounting design enables flexible and simplified installation.
Category: Pressure Regulators, Brand: AirTAC, Series: SDR
AirTAC SDR20008JN Precision Air Pressure Regulator Specifications
- Model: SDR20008JN
- Type: Precision pressure regulating valve with pressure gauge port
- Port size: PT1/4 (BSPP)
- Pressure adjustment range: 0.05–0.85 MPa
- Maximum pressure: 1.0 MPa
- Operating temperature: -20℃ to 60℃
- Flow capacity: 2,000 Nl/min (ANR)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (Nitrile rubber)
- Weight: 480g ±5%
- Dimensions: 98mm(H) × 50mm(W) × 102mm(D)
- Gauge thread: R1/8 (optional G1/8 adapter available)
- Pressure gauge range: 0–1.0 MPa (standard dial)
- Locking mechanism: Anti-vibration adjustment knob
- Mounting orientation: Vertical ±15°
Industrial-grade pressure regulator featuring dual-chamber diaphragm design for stable output under fluctuating input pressures. Integrated pressure relief valve prevents system over-pressurization. The chrome-plated adjustment knob includes tactile click stops for precise control (0.01 MPa increments). Compatible with ISO 8573-1:2010 Class 4 compressed air.
- Pneumatic tool pressure stabilization in assembly lines
- Packaging machine air circuit pressure management
- Medical gas pressure control systems
- Semiconductor manufacturing equipment
- Automated painting system pressure regulation
Installation note:
Install downstream of filter/lubricator units (FRL). For optimal performance:
- Pre-filter air to 5μm minimum
- Allow 30cm straight tubing upstream
- Drain condensate weekly via bottom vent
- Re-calibrate every 2,000 operating hours
| Property | Property Value |
|---|---|
| sku | SDR20008JN |
| Port Size | PT1/4 |
