Airtac SE32 Standard Cylinder SE32AX230S
The AirTAC SE32 Standard Cylinder SE32AX230S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 230mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke230 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32AX230S
The AirTAC SE32AX230S is a double-acting single-rod ISO 15552 profile cylinder engineered for compact automation. It generates 402 N of push force at 0.5 MPa and features a 230 mm stroke. The square extruded aluminum barrel removes external tie rods, yielding a flush body that resists corrosion and simplifies flush mounting on machinery.
This configuration integrates a SUS420J2 stainless steel rod for corrosive and washdown environments, alongside a built-in magnet for CMSE reed and DMSE electronic position sensing. Field-adjustable pneumatic cushioning at both ends allows you to fine-tune end-of-stroke deceleration, protecting payloads from hard impacts.
Airtac SE32 Standard Cylinder SE32AX230S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32AX230S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 230 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32AX230S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×230 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32AX230S Is Used
Lab Diagnostic Ejection
Uses the 402 N extend force and SUS420J2 rod to push sample vials out of chemical analyzers during washdown cycles.
PCB Router Gating
Actuates routing machine gates with a 230 mm travel, relying on the compact tie-rod-free profile to fit tight electronics assembly cells.
Carton Flap Folding
Folds small cardboard flaps on packaging lines, using adjustable cushioning to prevent crushing lightweight materials at high speeds.
Is the Airtac SE32 Standard Cylinder SE32AX230S the Right Cylinder?
Delivering 402 N push at 0.5 MPa, this 32 mm bore is the smallest ISO 15552 option. If your application requires more thrust, stepping up to the 40 mm bore yields 628 N push. Because this is a standard double-acting cylinder, it will not hold a load if air pressure drops or the valve centers; use a BSE rod lock for fail-safe positioning. For this 230 mm stroke, the 12 mm rod carries side loads well, but long unsupported travel still warrants an external guide to prevent rod-bearing bending. To retrofit an existing machine, match the 32 mm bore, 230 mm stroke, PT1/8 port, and add an -S magnet for sensor feedback.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32AX230S FAQ
At 0.5 MPa, the push force is 402 N and pull force is 345 N. At 0.7 MPa, push is 563 N. The maximum push is 82 kgf at 1.0 MPa. Operating speed ranges from 30 to 800 mm/s.
Yes, the SE32AX230S is dimensionally interchangeable per ISO 15552 standards. It uses a PT1/8 port and M10x1.25 rod thread, allowing a direct replacement for other ISO 15552 cylinders with matching mounting hardware.
