Airtac SE32 Standard Cylinder SE32BX130S
The AirTAC Airtac SE32 Standard Cylinder SE32BX130S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 130mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke130 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac SE32 Standard Cylinder SE32BX130S
The AirTAC SE32BX130S is a double-acting, single-rod ISO 15552 profile cylinder engineered for precise linear motion. Operating at 0.5 MPa, it generates 402 N of push force and 345 N of pull force. Its square extruded aluminum barrel omits external tie rods, yielding a compact footprint that mounts flush against machine frames while resisting mechanical corrosion.
This specific configuration features a SUS304 stainless steel rod (code B) for superior resilience in washdown or corrosive environments, alongside a built-in magnet (code S) for position sensing. The integrated sensor groove accommodates AirTAC CMSE reed and DMSE electronic switches without requiring additional brackets. Furthermore, pneumatic cushioning at both ends is field-adjustable via a set screw, allowing operators to tune end-of-stroke deceleration and eliminate hard mechanical impacts.
Airtac SE32 Standard Cylinder SE32BX130S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX130S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX130S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX130S Is Used
Lab Diagnostic Equipment
The SUS304 rod withstands chemical wipe-downs while the 402 N push force reliably actuates sample tray gates and testing head brackets across the 130 mm stroke.
Flow Wrapper Sealing
Provides precise 130 mm stroke movement for sealing jaw closure on compact packaging lines, where the adjustable cushion softens high-speed end stops.
PCB Handling Lifts
Lifts populated circuit boards between conveyor tiers, relying on the DMSE electronic sensor magnet for high-resolution position verification at stroke end.
Is the Airtac SE32 Standard Cylinder SE32BX130S the Right Cylinder?
With a 402 N push at 0.5 MPa, this 32 mm bore is ideal for compact actuation. If your payload requires less force, stepping down to a 25 mm bore reduces the footprint, whereas upgrading to a 40 mm bore increases push force to 628 N. For this 130 mm stroke, the PT1/8 port and M10x1.25 rod thread provide a balanced interface. Because this is a standard double-acting cylinder, it will drift if air pressure is lost or the valve centers; use an AirTAC BSE rod lock for strict position holding. Additionally, while the 12 mm rod handles moderate radial loads, any stroke over 300 mm requires an external guide to prevent rod-bearing bending.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX130S FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N of push force and 345 N of pull force. At 0.7 MPa, push force reaches 563 N, with a maximum push capacity of 82 kgf at 1.0 MPa. It operates at pressures from 0.15-1.0 MPa and speeds of 30-800 mm/s.
Yes, the SE32BX130S is dimensionally interchangeable per ISO 15552 / VDMA 24562 standards. You can drop it directly into existing mounting hardware without modifications. It uses a PT1/8 port and an M10x1.25 rod-end thread.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models usually ship in 3-4 days.
Fast Reply
Most inquiries answered within 7-8 hours.
Request a Quote for Airtac SE32 Standard Cylinder SE32BX130S
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
