Airtac SE32 Standard Cylinder SE32BX200SH
The AirTAC SE32 Standard Cylinder SE32BX200SH is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 200mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke200 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX200SH
The AirTAC SE32BX200SH is a double-acting single-rod ISO 15552 profile cylinder engineered for demanding environments. It delivers a push force of 402 N at 0.5 MPa, utilizing a SUS304 stainless steel rod for superior corrosion resistance in washdown duty. The FKM Viton seal expands the operating temperature range up to 150 C, making it suitable for high-heat processing lines.
This 32 mm bore unit features a square extruded aluminum barrel without external tie rods, allowing flush mounting and reducing trapped debris. The integrated magnet (-S) supports CMSE reed and DMSE electronic position sensors, while the field-adjustable air cushion at both ends lets you fine-tune end-of-stroke deceleration to eliminate hard mechanical impacts.
Airtac SE32 Standard Cylinder SE32BX200SH Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX200SH |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX200SH
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX200SH Is Used
Lab Diagnostic Centrifuge Loading
Cycles sample racks into a heated diagnostic centrifuge, utilizing the SUS304 rod and 150 C FKM seal to withstand ambient sterilization temperatures while applying 402 N of push force.
Food Pouch Heat Sealing
Actuates a heated sealing jaw on a packaging line, where the Viton seal resists thermal degradation and the tie-rod-free extruded profile prevents food debris accumulation.
PCB Conveyor Gate Diversion
Pivots a routing gate on an electronics assembly conveyor, using the integrated magnet with a DMSE electronic sensor to confirm stroke position for automated tracking.
Is the Airtac SE32 Standard Cylinder SE32BX200SH the Right Cylinder?
Selecting this 32 mm bore cylinder makes sense when your application requires 402 N of push force at 0.5 MPa within a compact footprint. If you need less force, there is no smaller standard ISO 15552 bore in this series. If your load demands more thrust, stepping up to the 40 mm bore provides 628 N of push at 0.5 MPa. Because this is a double-acting cylinder, it will drift if air pressure is lost or the valve is centered; use a BSE rod lock for position holding.
For direct retrofits, this model is dimensionally interchangeable per ISO 15552 with matching 32 mm bore, 200 mm stroke, PT1/8 port, and standard mounting accessories. Since the stroke is 200 mm, ensure the unsupported rod load is guided externally to prevent rod-bearing bending, as the 12 mm rod and M10x1.25 thread have limits on side load.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX200SH FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N of push force and 345 N of pull force. At 0.7 MPa, the push force increases to 563 N. The maximum push force is 82 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, the SE32BX200SH is dimensionally interchangeable per ISO 15552. You can use it as a direct replacement for other ISO 15552 profile cylinders with a 32 mm bore, 200 mm stroke, and PT1/8 port, sharing standard mounting accessories.
