Airtac SE32 Standard Cylinder SE32BX240S
The AirTAC SE32 Standard Cylinder SE32BX240S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 240mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke240 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX240S
The AirTAC SE32BX240S is a double-acting single-rod profile cylinder built to the ISO 15552 standard. It features a 32mm bore and a 240mm stroke, generating 402 N of push force at 0.5 MPa. The extruded aluminum barrel omits external tie rods, yielding a compact footprint that mounts flush against machine frames while resisting corrosion.
This specific configuration includes a SUS304 stainless steel rod (code B) for corrosive or washdown environments, and a built-in magnet (code S) for position detection. The magnet interfaces directly with AirTAC CMSE reed and DMSE electronic sensors housed in the three integrated barrel grooves.
Airtac SE32 Standard Cylinder SE32BX240S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX240S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 240 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX240S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×240 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX240S Is Used
Lab Diagnostic Ejector
Uses the 402 N extend force to push tested vial racks out of a washdown centrifuge, relying on the SUS304 rod to resist chemical cleaning agents.
Pouch Folding Arm
Actuates a 240mm stroke folding blade on a vertical form-fill-seal machine, where the adjustable cushion softens the shift from fast travel to a precise crease.
PCB Router Gate
Indexes a safety guard on a circuit board depaneling router, using the integrated magnet with a DMSE electronic sensor to confirm door closure before the spindle starts.
Is the Airtac SE32 Standard Cylinder SE32BX240S the Right Cylinder?
At 0.5 MPa, this 32mm bore yields 402 N of push force. If your application requires less force, the next size down does not exist in the ISO 15552 standard, but if you need substantially more power, stepping up to the 40mm bore provides 628 N of push. Because the stroke is 240mm, the unsupported piston rod length increases; use an external guide to prevent rod-bearing bending under side loads.
This cylinder is dimensionally interchangeable per ISO 15552, serving as a direct replacement for other ISO 15552 cylinders. It uses a PT1/8 port, a 12mm rod, and field-adjustable air cushions at both ends to soften end stops. Note that a plain SE cylinder drifts when air pressure is lost; use a BSE rod lock if the load must be held without live pressure.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX240S FAQ
At 0.5 MPa, the push force is 402 N and the pull force is 345 N. At 0.7 MPa, the push force is 563 N. The maximum push force is 82 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes. The SE32BX240S is dimensionally interchangeable per ISO 15552, meaning it shares the exact same mounting footprint and port sizes (PT1/8) as other standard 32mm profile cylinders, making it a direct replacement.
