Airtac SE32 Standard Cylinder SE32BX250S
The AirTAC SE32 Standard Cylinder SE32BX250S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 250mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke250 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX250S
The AirTAC SE32BX250S is a double-acting, single-rod ISO 15552 profile cylinder engineered for precise linear motion. Operating at 0.5 MPa, it provides 402 N of push force and 345 N of pull force, peaking at a maximum push of 82 kgf at 1.0 MPa. Because it features a SUS304 stainless steel rod (code B), this specific configuration is purpose-built for corrosive environments and washdown duty.
Unlike traditional tie-rod designs, the SE series utilizes a square extruded aluminum barrel that mounts flush while leaving sensor grooves open on three sides. The integrated magnet (code S) enables direct position tracking using AirTAC CMSE reed or DMSE electronic sensors. Furthermore, the pneumatic cushioning at both ends is field-adjustable via a screw, allowing you to tune end-stop deceleration for the 30-800 mm/s speed range.
Airtac SE32 Standard Cylinder SE32BX250S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX250S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 250 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX250S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×250 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX250S Is Used
Flow Wrapper Sealing Jaw
Drives the sealing jaw on continuous flow wrappers, utilizing the 402 N push force and 250 mm stroke to cleanly cut and seal packaging film in food processing areas.
Lab Sample Dispenser
Actuates fluid dispensing valves in chemical laboratories, where the SUS304 stainless steel rod provides necessary resistance to solvents and frequent washdowns.
Package Diverter Gate
Pivots diverter arms on sorting conveyor lines, relying on the integrated magnet and DMSE electronic sensors to confirm package routing positions at high speeds.
Is the Airtac SE32 Standard Cylinder SE32BX250S the Right Cylinder?
When sizing this 32 mm bore model, consider stepping up to the 40 mm bore if you need more thrust (628 N push at 0.5 MPa), or stepping down to a smaller unit if 402 N is excessive for your payload. As a standard ISO 15552 cylinder, it serves as a direct replacement sharing the exact same mounting interface and footprint as other ISO 15552 cylinders. To fully match your existing setup, verify the 250 mm stroke, PT1/8 port, and your preferred mounting accessory. Because the stroke is 250 mm, the 12 mm rod and M10x1.25 thread should be guided externally if subjected to heavy lateral loads to prevent rod-bearing bending. Note that a plain SE does not hold its load when air is lost; for position holding, explore a BSE rod lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX250S FAQ
The SE32BX250S generates 402 N of push force and 345 N of pull force at 0.5 MPa. At 0.7 MPa, the push force is 563 N. The absolute maximum push force is 82 kgf when operated at the maximum rated pressure of 1.0 MPa.
Yes, the SE32BX250S is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact mounting interface and can serve as a direct replacement for other ISO 15552 profile cylinders without altering your hardware.
