Airtac SE40 Standard Cylinder SE40AX100SH
The AirTAC SE40 Standard Cylinder SE40AX100SH is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ40 mm
- Stroke100 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM12×1.25
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE40 Standard Cylinder SE40AX100SH
The AirTAC SE40AX100SH is a double-acting single-rod profile cylinder built to the ISO 15552 standard. It delivers 628 N of push force and 528 N of pull force at 0.5 MPa, operating via a 16 mm SUS420J2 stainless steel rod. The square extruded aluminum barrel omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames.
This specific configuration pairs a high-temperature Viton (FKM) seal—expanding the operating range up to 150 C—with a built-in magnet for CMSE and DMSE position sensors. Field-adjustable pneumatic cushioning at both ends lets you tune the end-of-stroke deceleration to protect tooling and payloads.
Airtac SE40 Standard Cylinder SE40AX100SH Technical Specifications
| Model | Airtac SE40 Standard Cylinder SE40AX100SH |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE40 Standard Cylinder SE40AX100SH
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE40 Standard Cylinder SE40AX100SH Is Used
Shrink Wrap Tunnels
Handles carton actuation inside 150 C heat tunnels, utilizing the Viton FKM seal and SUS420J2 stainless rod to survive continuous thermal exposure while pushing with 628 N.
Divertor Gates
Mounts flush using the ISO 15552 profile to deflect packages on food-grade washdown lines, where the tie-rod-free exterior and stainless rod resist moisture and detergent corrosion.
Lab Oven Doors
Provides reliable 100 mm stroke automation for high-temperature laboratory oven doors, using the built-in magnet to trigger DMSE electronic sensors for precise closure confirmation.
Is the Airtac SE40 Standard Cylinder SE40AX100SH the Right Cylinder?
If you need less force, the 32 mm bore variant provides 402 N of push at 0.5 MPa; for heavier drives, stepping up to the 50 mm bore yields 982 N. This 40 mm bore features a PT1/4 port, a 100 mm stroke, and a basic mounting interface. Since the stroke is 100 mm, side-load is manageable, but long unsupported strokes still require an external guide to prevent rod-bearing bending. Remember that a standard SE cylinder will drift if air pressure is lost; for position holding, consider the BSE rod lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE40 Standard Cylinder SE40AX100SH FAQ
At 0.5 MPa, this 40 mm bore cylinder provides 628 N push and 528 N pull force. At 0.7 MPa, the push force is 879 N, with a maximum push of 128 kgf at 1.0 MPa. It operates at 30-800 mm/s and handles temperatures up to 150 C thanks to the Viton FKM seal.
Yes, the SE40AX100SH is dimensionally interchangeable per ISO 15552, acting as a direct replacement for other standard profile cylinders. You can reuse existing mounting hardware while gaining AirTAC's adjustable air cushions and a SUS420J2 stainless rod for washdown environments.
