Airtac SE40 Standard Cylinder SE40AX175S
AirTAC SE40AX175S Standard Cylinder Specifications
- Model: SE40AX175S
- Bore size: 40 mm
- Stroke: 175 mm
- Operating pressure: 0.15–1.0 MPa
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushioning type: Adjustable air cushion (both ends)
- Piston speed: 50–1000 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Mounting type: Basic type (accessory mountings available)
- Rod rotation: Non-rotating design
- Weight: 1.53 kg (with standard fittings)
- Dimensions: 254mm(L) × 50mm(W) × 50mm(H) (fully retracted)
- Rod thread: M10x1.25
- Max theoretical thrust: 126N @ 0.63MPa
- ISO standard: 6431 compliant
- JIS standard: B8377 compliant
High-precision industrial cylinder with chromium-plated piston rod and hard anodized aluminum tube. Features dual adjustable cushions for smooth end-of-stroke deceleration and magnetic piston for position sensing compatibility. Maintenance-free design with integrated wear-resistant guide rings ensures over 3,000km service life under standard conditions.
- Automated assembly line clamping mechanisms
- Packaging machine ejection systems
- CNC machine tool part positioning
- Material handling transfer units
- Printing press paper feed systems
Installation note:
Maintain 0.5–1mm clearance between rod end and load during alignment.
Lubricate through air supply (ISO VG32 recommended).
For vertical mounting, use SA/SU series brackets for stability.
Critical parameters:
Max side load capacity 35N | Max moment load 6.5N·m |
Do not exceed 80% of theoretical thrust in continuous duty cycles
| Property | Property Value |
|---|---|
| sku | SE40AX175S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | SUS420J2 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 175mm |
