Airtac SE50 Standard Cylinder SE50X200
The AirTAC SE50 Standard Cylinder SE50X200 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø50mm bore and 200mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke200 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE50 Standard Cylinder SE50X200
The AirTAC SE50X200 is a double-acting single-rod ISO 15552 profile cylinder delivering a 982 N push force at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames. This clean profile prevents debris buildup while streamlining sensor placement along the integrated three-side grooves.
Field-adjustable pneumatic cushioning at both stroke ends allows you to tune end-of-travel deceleration via a set screw, softening hard impacts at operating speeds up to 800 mm/s. This specific SKU is configured without a built-in magnet, so it operates as a purely pneumatic drive without position feedback unless externally monitored. The 200 mm stroke is driven by a 20 mm hard-chrome rod with an M16x1.5 thread.
Airtac SE50 Standard Cylinder SE50X200 Technical Specifications
| Model | Airtac SE50 Standard Cylinder SE50X200 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE50 Standard Cylinder SE50X200
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 50 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE50 Standard Cylinder SE50X200 Is Used
Carton Flap Folding
Provides the 982 N push at 0.5 MPa needed to positively fold heavy corrugated carton flaps during case sealing lines.
Bottling Line Diverter
Uses the 200 mm stroke to push glass containers smoothly between parallel conveyor belts without tie-rod snags.
CNC Fixture Clamping
Secures aluminum castings inside machining centers, benefiting from the adjustable cushion to soften end stops at speed.
Is the Airtac SE50 Standard Cylinder SE50X200 the Right Cylinder?
Selecting the 50 mm bore is ideal when your load requires roughly 100 kgf of thrust. If you need less force, stepping down to the 40 mm bore yields 628 N push at 0.5 MPa, whereas upgrading to the 63 mm bore provides 1559 N push for heavier payloads. Because this is a standard double-acting cylinder, it will drift if air pressure is lost or the valve is centered; applications requiring true position holding should integrate an external pilot-operated check valve or select the BSE rod-lock variant.
At 200 mm of stroke, the 20 mm rod and M16x1.5 thread handle moderate side loads, but long unsupported strokes can induce rod-bearing bending—always use an external guide for heavy lateral loads. As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct replacement for other ISO 15552 cylinders, sharing standard mounting accessories like FA front flanges or LB foot brackets. It uses a PT1/4 port.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE50 Standard Cylinder SE50X200 FAQ
The SE50X200 provides a push force of 982 N and a pull force of 825 N at 0.5 MPa. At 0.7 MPa, the push force is 1374 N. The maximum push force is 200 kgf at 1.0 MPa.
Yes, the SE50X200 is dimensionally interchangeable per ISO 15552 standards. It shares the same mounting interface and PT1/4 port sizes, allowing it to function as a direct replacement for other ISO 15552 profile cylinders.
