AirTAC SE Series · ISO 15552 Cylinder

Airtac SE50 Standard Cylinder SE50X300

The AirTAC SE50 Standard Cylinder SE50X300 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø50mm bore and 300mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ50 mm
  • Stroke300 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 30 mm
$94.31 $101.81Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE50 stroke, mounting and version on one page All SE50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE50 Standard Cylinder SE50X300

The AirTAC SE50X300 is a double-acting single-rod profile cylinder built to the ISO 15552 standard, delivering a robust 982 N push force at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames. This clean profile simplifies fabrication while maintaining the rigorous dimensional footprint required for global interchangeability.

This specific configuration features a 300 mm stroke and a standard PT1/4 port. Because this SKU lacks the built-in magnet option, it operates without electronic position feedback, relying instead on its field-adjustable air cushioning at both ends. You can tune the cushion screws to precisely decelerate the piston near stroke end, softening hard impacts during high-speed cycling.

Airtac SE50 Standard Cylinder SE50X300 Technical Specifications

ModelAirtac SE50 Standard Cylinder SE50X300
SeriesSE ISO 15552 profile cylinder
Bore sizeØ50 mm
Stroke300 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa982 N825 N
0.7 MPa1374 N—
Max (@1.0 MPa)200 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE50 Standard Cylinder SE50X300

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
50Bore size in mm.
×300Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE50 Standard Cylinder SE50X300 Is Used

conveyor_belt

Packaging Line Diverter

Uses the 300 mm stroke to push cartons between adjacent conveyor lanes, relying on the 982 N push force to handle heavy packaged goods without bouncing.

precision_manufacturing

CNC Lathe Door Operator

Cycles the heavy sliding safety door of a CNC lathe, where the adjustable end cushions soften the 300 mm travel to protect the machine enclosure from slamming.

warehouse

Palletizing Stop Gate

Acts as a physical stop for pallets on a roller conveyor, utilizing the ISO 15552 profile body for flush mounting and the 825 N pull force to retract the gate.

Is the Airtac SE50 Standard Cylinder SE50X300 the Right Cylinder?

Selecting the SE50X300 is ideal when your application requires a mid-range 982 N push at 0.5 MPa. If you need less force and a smaller footprint, stepping down to the 40 mm bore yields 628 N of push. Conversely, if your load demands more power, stepping up to the 63 mm bore provides 1559 N. This model uses a PT1/4 port and standard ISO 15552 mounting accessories, making it a direct replacement for any standard 50 mm profile cylinder.

Because this unit features a 300 mm stroke, the extended rod is subject to increased bending moments and side loads. Even with the standard Ø20 mm rod and M16x1.5 thread, an unsupported load at this extension length can damage the rod bearing, so an external guide mechanism is highly recommended. Note that a plain SE cylinder will drift if air pressure is lost or the valve is centered; it cannot hold a load without live pressure, so consider a BSE rod lock variant if position holding is required.

AirtacDistr lists every SE50 order code with its price on one page at https://airtacdistr.com/products/airtac-se50-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE50 Standard Cylinder SE50X300 FAQ

The SE50X300 generates 982 N of push force and 825 N of pull force at 0.5 MPa. At 0.7 MPa, the push force increases to 1374 N, with a maximum push capacity of 200 kgf at 1.0 MPa. The operating speed range for this 50 mm bore cylinder is 30-800 mm/s.

Yes, it is dimensionally interchangeable with any standard ISO 15552 profile cylinder, matching standard mounting and PT1/4 port locations. This specific SKU does not have a built-in magnet, so it cannot host CMSE or DMSE position sensors without modifying the piston assembly.
