Airtac SE50 Standard Cylinder SE50X50
The AirTAC SE50 Standard Cylinder SE50X50 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø50mm bore and 50mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ50 mm
- Stroke50 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE50 Standard Cylinder SE50X50
The AirTAC SE50X50 is a double-acting, single-rod ISO 15552 profile cylinder engineered to deliver 982 N of push force and 825 N of pull force at 0.5 MPa. Its square extruded aluminum barrel omits external tie rods, yielding a compact, flush-mounting body that resists corrosion and simplifies bracket installation.
This specific SKU lacks the built-in position-sensor magnet, meaning it operates blind without CMSE or DMSE switches. To absorb kinetic energy at the 50 mm stroke endpoints, field-adjustable air cushioning at both ends allows technicians to dial in the exact deceleration rate required by the moving load.
Airtac SE50 Standard Cylinder SE50X50 Technical Specifications
| Model | Airtac SE50 Standard Cylinder SE50X50 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 50 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE50 Standard Cylinder SE50X50
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 50 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE50 Standard Cylinder SE50X50 Is Used
Carton Flap Folding
Drives the mechanical arms that fold corrugated carton flaps prior to tape sealing, utilizing the 982 N push force to overcome cardboard stiffness within a compact 50 mm stroke.
Bottle Diverting Gate
Actuates a routing gate on a bottling conveyor line, relying on the tie-rod-free aluminum profile to mount flush against the guardrails without snagging passing containers.
Press Die Ejection
Ejects small stamped metal parts from a lower die bed, where the 30 mm adjustable cushion length smoothly decelerates the 20 mm rod to prevent marking the finished components.
Is the Airtac SE50 Standard Cylinder SE50X50 the Right Cylinder?
When sizing this 50 mm bore, stepping down to a 40 mm cylinder reduces the 0.5 MPa push capacity to 628 N, while stepping up to a 63 mm bore increases it to 1559 N. Because this model has no -S magnet, direct ISO 15552 retrofits requiring position feedback must specify the SE50X50S variant instead. Standard PT1/4 ports and a 20 mm rod accommodate typical mid-range loads.
Note that a standard double-acting cylinder drifts when air pressure is removed or a valve centers; it cannot hold a load statically without live pressure. If your fixture demands mechanical locking upon pressure loss, consider the BSE rod-lock variant rather than relying on the cushions, which only decelerate the piston near stroke end.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE50 Standard Cylinder SE50X50 FAQ
At 0.5 MPa, the SE50X50 provides 982 N of push force and 825 N of pull force. At 0.7 MPa, the push force is 1374 N, with a maximum push capacity of 200 kgf at 1.0 MPa. The air supply port size is PT1/4.
Yes, the SE50X50 shares the exact ISO 15552 / VDMA 24562 mounting interface and body dimensions, allowing it to serve as a direct replacement for other ISO 15552 profile cylinders. Just ensure your mounting hardware and PT1/4 pneumatic connections align.
