Airtac SE63 Standard Cylinder SE63AX100S
The AirTAC SE63 Standard Cylinder SE63AX100S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 100mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke100 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE63 Standard Cylinder SE63AX100S
The AirTAC SE63AX100S is a double-acting, single-rod ISO 15552 profile cylinder engineered for pneumatic automation. It features a 63 mm bore and a 100 mm stroke, generating 1559 N of push force at 0.5 MPa and 2182 N at 0.7 MPa. The extruded aluminum barrel design omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush in tight machine cavities.
This configuration integrates a SUS420J2 stainless steel rod (code A) for superior resistance to corrosion and washdown environments. The built-in magnet (code S) enables seamless position detection with AirTAC CMSE reed or DMSE electronic sensors. Field-adjustable pneumatic cushioning at both stroke ends allows technicians to tune end-of-stroke deceleration, softening hard impacts during high-speed operation.
Airtac SE63 Standard Cylinder SE63AX100S Technical Specifications
| Model | Airtac SE63 Standard Cylinder SE63AX100S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE63 Standard Cylinder SE63AX100S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 63 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE63 Standard Cylinder SE63AX100S Is Used
Flow Wrapper End-Sealing
Drives the sealing jaw mechanism on continuous-motion flow wrappers, utilizing the 1559 N push force and SUS420J2 rod to withstand daily washdowns in food packaging facilities.
Bottle Diverting Gate
Actuates stainless steel diverter arms on high-speed bottling lines, where the 100 mm stroke rapidly redirects containers without corroding from frequent splash exposure.
CNC Lathe Unloader
Pushes finished spindles out of a CNC lathe enclosure, using the adjustable end cushions to prevent marring delicate metal surfaces during rapid 30-800 mm/s ejection.
Is the Airtac SE63 Standard Cylinder SE63AX100S the Right Cylinder?
Selecting this 63 mm bore provides a robust middle ground, delivering 1559 N push at 0.5 MPa. If your load is lighter, stepping down to the 50 mm bore yields 982 N push, whereas moving up to the 80 mm bore provides 2513 N. This SE63AX100S features a PT3/8 port, a 100 mm stroke, and an S magnet for CMSE / DMSE sensors. Keep in mind that a standard SE cylinder relies on live air pressure to hold its position; if air is lost, the piston drifts. For applications requiring mid-stroke holding without continuous pressure, consider the BSE rod-lock variant. At 100 mm stroke, side-load stress on the rod bearing is minimal, but an external guide is recommended for any unsupported lateral loads.
Because it adheres to the ISO 15552 / VDMA 24562 dimensional standard, this cylinder functions as a direct replacement for other ISO 15552 profile cylinders, simplifying retrofits and sharing mounting hardware like FA front flanges or TC trunnions.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE63 Standard Cylinder SE63AX100S FAQ
At 0.5 MPa, the SE63AX100S delivers 1559 N of push force and 1402 N of pull force. At 0.7 MPa, the push force is 2182 N, with a maximum push capacity of 318 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes. The SE63AX100S is dimensionally interchangeable per ISO 15552 / VDMA 24562 standards. It shares the exact 63 mm bore mounting footprint and PT3/8 port locations, allowing it to serve as a direct replacement for other ISO 15552 profile cylinders without altering your machine base.
