Airtac SE63 Standard Cylinder SE63AX105S
The AirTAC SE63 Standard Cylinder SE63AX105S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 105mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke105 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE63 Standard Cylinder SE63AX105S
The AirTAC SE63AX105S is a double-acting single-rod ISO 15552 profile cylinder engineered for rigorous washdown and corrosive environments. Equipped with a SUS420J2 stainless steel rod, it delivers a robust 1559 N push force at 0.5 MPa across its 105 mm stroke. The extruded aluminum barrel design omits external tie rods, yielding a compact, flush-mounting body that resists debris buildup.
This 63 mm bore unit features a built-in position magnet for CMSE or DMSE sensors and operates at speeds of 30-800 mm/s. Field-adjustable pneumatic cushioning at both end caps allows technicians to tune deceleration via a set screw, softening hard mechanical stops during high-cycle operations.
Airtac SE63 Standard Cylinder SE63AX105S Technical Specifications
| Model | Airtac SE63 Standard Cylinder SE63AX105S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 105 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE63 Standard Cylinder SE63AX105S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 63 | Bore size in mm. |
| ×105 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE63 Standard Cylinder SE63AX105S Is Used
Bottling Line Diverters
Actuates routing gates on beverage filling lines, utilizing the SUS420J2 stainless rod to withstand constant moisture and chemical washdowns while delivering 1559 N push force.
Corrugated Box Flap Folders
Drives mechanical arms to fold heavy cardboard flaps at high speed, relying on the 105 mm stroke and adjustable end cushions to prevent impact damage over thousands of cycles.
Seafood Processing Ejectors
Pushes sorted product into packaging chutes in saline environments, leveraging the corrosion-resistant rod material and built-in magnet for DMSE electronic position confirmation.
Is the Airtac SE63 Standard Cylinder SE63AX105S the Right Cylinder?
Selecting this 63 mm bore cylinder makes sense when your application requires the 1559 N push at 0.5 MPa provided by this model. If your load is lighter, stepping down to the 50 mm bore yields 982 N of push force, whereas stepping up to the 80 mm bore provides 2513 N for heavier payloads. Because this is a 105 mm stroke, side-loading on the rod bearing is minimal, but always ensure the load is guided externally to prevent premature seal wear.
As a standard ISO 15552 profile cylinder with a PT3/8 port, it serves as a direct dimensional replacement for any equivalent ISO 15552 cylinder. Note that the adjustable air cushion only decelerates the piston near stroke end; it cannot hold a load vertically if air pressure is lost. For position-holding safety, consider the BSE rod lock variant or an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE63 Standard Cylinder SE63AX105S FAQ
At 0.5 MPa, this 63 mm bore cylinder provides 1559 N of push force and 1402 N of pull force. At 0.7 MPa, the push force increases to 2182 N, with a maximum push capacity of 318 kgf at 1.0 MPa. It features a PT3/8 port, a 20 mm SUS420J2 stainless steel rod, and operates at speeds between 30-800 mm/s.
Yes, the SE63AX105S is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact same mounting footprint and interface as other standard profile cylinders. It is a true double-acting profile cylinder with an extruded aluminum barrel, not a tie-rod type, allowing for straightforward retrofits.
