Airtac SE63 Standard Cylinder SE63AX130S
The AirTAC SE63 Standard Cylinder SE63AX130S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 130mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ63 mm
- Stroke130 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE63 Standard Cylinder SE63AX130S
The AirTAC SE63AX130S is a double-acting, single-rod ISO 15552 profile cylinder engineered for demanding washdown and corrosive environments. It features a SUS420J2 stainless steel piston rod (material code A) that resists rust and chemical degradation far better than standard carbon steel. Delivering a robust 1559 N push force at 0.5 MPa, this 63 mm bore unit is built to handle substantial workloads while maintaining a compact, clean exterior.
Unlike traditional tie-rod cylinders, the SE series utilizes a square extruded aluminum barrel without external tie rods, making it significantly easier to mount flush against machine frames without snagging. The integrated magnet (code S) allows seamless positioning feedback using AirTAC CMSE reed or DMSE electronic sensors directly in the body's three sensor grooves. Additionally, the field-adjustable pneumatic cushioning at both stroke ends can be tuned via a set screw to soften hard end stops during high-speed operations.
Airtac SE63 Standard Cylinder SE63AX130S Technical Specifications
| Model | Airtac SE63 Standard Cylinder SE63AX130S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1559 N | 1402 N |
| 0.7 MPa | 2182 N | — |
| Max (@1.0 MPa) | 318 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE63 Standard Cylinder SE63AX130S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 63 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE63 Standard Cylinder SE63AX130S Is Used
Flow Wrapper Sealing
Drives the end-seal jaw on a continuous flow wrapper, utilizing the 1559 N push force and 130 mm stroke to cleanly crimp and cut packaging film at high cycle rates.
Benchtop Centrifuge Eject
Acts as the discharge ram for a pharmaceutical centrifuge, where the SUS420J2 stainless rod provides necessary resistance to caustic cleaning agents and washdown moisture.
Pallet Diverter Gate
Powers a pop-up sorting gate on a stainless steel conveyor line, using the built-in -S magnet and DMSE sensors to confirm gate position before product routing.
Is the Airtac SE63 Standard Cylinder SE63AX130S the Right Cylinder?
When sizing this actuator, compare its 1559 N push force at 0.5 MPa against its neighbors: step down to a 50 mm bore for lighter loads (982 N push), or step up to an 80 mm bore for heavier tasks (2513 N push). Because this is a double-acting cylinder, it relies on live air pressure to move; it does not hold its position if air is lost or a valve is centered. If your process requires static load holding without air, you should integrate an external pilot-operated check valve or evaluate the BSE rod-lock variant. To retrofit this into an existing setup, match the 63 mm bore, 130 mm stroke, PT3/8 port, and your required mounting accessory (like an FA front flange or TC trunnion).
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE63 Standard Cylinder SE63AX130S FAQ
At 0.5 MPa, this 63 mm bore cylinder provides 1559 N of push force and 1402 N of pull force. At 0.7 MPa, the push force increases to 2182 N. The maximum allowable push force is 318 kgf at 1.0 MPa operating pressure.
Yes, the SE63AX130S is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact same mounting footprint and hole patterns. You can drop it in as a replacement for other ISO 15552 profile cylinders, retaining your existing FA, LB, or TC mounting hardware.
