AirTAC SE Series · ISO 15552 Cylinder

Airtac SE63 Standard Cylinder SE63X160

The AirTAC SE63 Standard Cylinder SE63X160 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 160mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke160 mm
  • Port sizePT3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$95.34 $102.84Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE63 stroke, mounting and version on one page All SE63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE63 Standard Cylinder SE63X160

The AirTAC SE63X160 is a double-acting, single-rod ISO 15552 profile cylinder engineered for demanding pneumatic tasks. It delivers a robust 1559 N push force at 0.5 MPa (2182 N at 0.7 MPa) across its 160 mm stroke. Built with a square extruded aluminum barrel, this unit omits external tie rods, yielding a highly compact, corrosion-resistant body that mounts flush against machine frames.

This specific SKU lacks a built-in magnet, meaning it ships without position sensing out of the box. Deceleration is handled by field-adjustable air cushions at both ends, allowing technicians to dial in end-of-stroke speeds via a simple screw rather than relying on fixed rubber bumpers.

Airtac SE63 Standard Cylinder SE63X160 Technical Specifications

ModelAirtac SE63 Standard Cylinder SE63X160
SeriesSE ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke160 mm
Acting typeDouble acting
Port sizePT3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1559 N1402 N
0.7 MPa2182 N—
Max (@1.0 MPa)318 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE63 Standard Cylinder SE63X160

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
63Bore size in mm.
×160Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE63 Standard Cylinder SE63X160 Is Used

straighten

Press Die Ejection

Provides the 1559 N push at 0.5 MPa needed to eject stamped metal sheets from press dies, using the 160 mm stroke to clear the lower bolster safely.

conveyor_belt

Pallet Diverting

Actuates routing arms on packaging conveyor lines, where the extruded no-tie-rod profile prevents debris buildup and allows flush side mounting.

precision_manufacturing

CNC Spindle Clamping

Locks auxiliary spindle attachments on multi-axis machining centers, relying on adjustable end cushions to soften the 160 mm stroke impact at high cycle rates.

Is the Airtac SE63 Standard Cylinder SE63X160 the Right Cylinder?

If 1559 N of push at 0.5 MPa is too much for your fixture, stepping down to the 50 mm bore yields 982 N. Conversely, if you need to move heavier jigs, the 80 mm bore provides 2513 N. Remember that a plain SE cylinder will drift and cannot hold a load if air pressure drops or the valve centers; for fail-safe holding, consider the BSE rod-lock variant. To match this exact unit for an ISO 15552 retrofit, specify a 63 mm bore, 160 mm stroke, PT3/8 port, and your preferred mounting accessory. At 160 mm stroke, side-load stress on the M16x1.5 rod thread remains moderate, but always verify bearing wear if guiding heavy offset loads.

AirtacDistr lists every SE63 order code with its price on one page at https://airtacdistr.com/products/airtac-se63-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE63 Standard Cylinder SE63X160 FAQ

At 0.5 MPa, the push force is 1559 N and the pull force is 1402 N. At 0.7 MPa, the push force reaches 2182 N. The maximum push force is 318 kgf when operating at the 1.0 MPa pressure limit.

Yes, the SE63X160 is dimensionally interchangeable per ISO 15552 / VDMA 24562 standards, serving as a direct replacement for other ISO 15552 profile cylinders using the same mounting hardware and PT3/8 port.
