AirTAC SE Series · ISO 15552 Cylinder

Airtac SE63 Standard Cylinder SE63X250

The AirTAC SE63 Standard Cylinder SE63X250 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 250mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke250 mm
  • Port sizePT3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$105.68 $113.18Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE63 stroke, mounting and version on one page All SE63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE63 Standard Cylinder SE63X250

The AirTAC SE63X250 is a double-acting single-rod ISO 15552 profile cylinder with a 63 mm bore and 250 mm stroke. It delivers 1559 N of push force and 1402 N of pull force at 0.5 MPa, making it well-suited for mid-weight industrial actuation. The extruded aluminum barrel omits external tie rods, yielding a compact, flush-mounting body that resists corrosion and simplifies fixture integration.

This unit features field-adjustable air cushioning at both ends to soften end-of-stroke impacts, operating via a needle screw rather than a fixed rubber bumper. It uses a PT3/8 port and a 20 mm hard-chrome rod, and because this SKU lacks the -S magnet suffix, it is not equipped for CMSE or DMSE position sensing out of the box.

Airtac SE63 Standard Cylinder SE63X250 Technical Specifications

ModelAirtac SE63 Standard Cylinder SE63X250
SeriesSE ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke250 mm
Acting typeDouble acting
Port sizePT3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1559 N1402 N
0.7 MPa2182 N—
Max (@1.0 MPa)318 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE63 Standard Cylinder SE63X250

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
63Bore size in mm.
×250Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE63 Standard Cylinder SE63X250 Is Used

conveyor_belt

Pallet Diverters

Provides the 1559 N push force at 0.5 MPa required to reroute heavy timber pallets along a transfer line, using the 250 mm stroke to clear adjacent lanes.

packaging

Case Erector Flaps

Folds corrugated cardboard box flaps at high cycle rates, relying on the field-adjustable end cushions to prevent hard mechanical slamming at the 250 mm extension.

factory

Injection Mould Guard

Actuates a heavy safety gate on an injection moulding machine, where the tie-rod-free extruded profile mounts flush to the frame to save floor space.

Is the Airtac SE63 Standard Cylinder SE63X250 the Right Cylinder?

If 1559 N of push at 0.5 MPa is too much force, step down to the 50 mm bore offering 982 N; if you need more power, step up to the 80 mm bore providing 2513 N. As a standard ISO 15552 cylinder, this model serves as a direct replacement for any matching 63 mm bore and 250 mm stroke profile cylinder, utilizing the same PT3/8 port and standardized mounting accessories. Because the stroke is 250 mm, the 20 mm rod and its bearing are subject to bending moments under heavy side loads, so an external guide rail is recommended to prevent premature seal wear. Note that the air cushion only decelerates the piston near the stroke ends; it cannot hold a load vertically if air pressure is lost, which would require a BSE rod lock variant.

AirtacDistr lists every SE63 order code with its price on one page at https://airtacdistr.com/products/airtac-se63-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE63 Standard Cylinder SE63X250 FAQ

At 0.5 MPa, the SE63X250 provides 1559 N of push force and 1402 N of pull force. At 0.7 MPa, the push force increases to 2182 N. The maximum push force is 318 kgf when operated at the 1.0 MPa pressure limit.

No. The field-adjustable air cushion at both ends only decelerates the piston near the stroke limits; it is not a mechanical brake. If the air supply is lost or the valve is centered, the cylinder will drift. For true load-holding without live pressure, an external pilot-operated check valve or a BSE rod lock variant is required.
