Airtac SE80 Standard Cylinder SE80AX1000S
The AirTAC Airtac SE80 Standard Cylinder SE80AX1000S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke1000 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX1000S
The AirTAC SE80AX1000S is a double-acting single-rod profile cylinder built to the ISO 15552 standard, delivering a robust 2513 N push force at 0.5 MPa. It features a SUS420J2 stainless steel rod (code A) for superior corrosion resistance in washdown or humid environments. The square extruded aluminum barrel omits external tie rods, yielding a compact footprint that mounts flush against machine frames while protecting internal components.
Equipped with a built-in position magnet (code S), this unit seamlessly integrates with AirTAC CMSE reed and DMSE electronic sensors for precise end-of-stroke detection. Field-adjustable air cushioning at both ends allows technicians to tune deceleration via a set screw, softening hard impacts when cycling heavy loads at speeds up to 800 mm/s.
Airtac SE80 Standard Cylinder SE80AX1000S Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX1000S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX1000S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX1000S Is Used
Pallet Transfer Diverters
Drives heavy pallet lane diverters where the 1000 mm stroke shifts loads between conveyor lines, utilizing the 2513 N push force to overcome sliding friction.
Volumetric Fillers
Actuates the main dosing gate on large-scale powder filling machines, relying on the SUS420J2 stainless rod to withstand daily chemical washdowns.
Automated Press Ejection
Pushes stamped metal parts out of a 80-ton hydraulic press, using the adjustable pneumatic cushion to absorb the kinetic energy of the 1000 mm extension.
Is the Airtac SE80 Standard Cylinder SE80AX1000S the Right Cylinder?
Selecting this 80 mm bore makes sense when substantial thrust is required without jumping to the larger 100 mm size (which yields 3927 N push at 0.5 MPa). Conversely, if the 2513 N push at 0.5 MPa exceeds your requirement, stepping down to the 63 mm bore provides 1559 N. Because this model features a 1000 mm stroke, the 25 mm rod and internal bearing face significant bending moments under side loads; always pair it with an external linear guide to prevent premature seal wear.
As a true ISO 15552 profile cylinder, it provides drop-in dimensional interchangeability for retrofitting existing 80 mm bore setups using the same PT3/8 ports and mounting accessories. Note that the adjustable cushion only decelerates the piston near stroke end and does not hold the load; if air pressure drops, the cylinder drifts, requiring a BSE rod lock for secure positioning.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX1000S FAQ
This 80 mm bore cylinder delivers 2513 N push and 2268 N pull at 0.5 MPa, 3518 N push at 0.7 MPa, and a maximum push of 513 kgf at 1.0 MPa. The operating speed range is 30-800 mm/s.
Yes, the SE80AX1000S is dimensionally interchangeable per ISO 15552, matching standard mounting footprints and PT3/8 port locations. It is a drop-in replacement for other ISO 15552 profile cylinders, though you must verify overall length tolerances.
