Airtac SE80 Standard Cylinder SE80AX105S
The AirTAC Airtac SE80 Standard Cylinder SE80AX105S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 105mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke105 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX105S
The AirTAC SE80AX105S is a double-acting, single-rod ISO 15552 profile cylinder engineered for demanding motion control. It features an 80 mm bore and a 105 mm stroke, generating a substantial 2513 N of push force at 0.5 MPa and 3518 N at 0.7 MPa. The extruded aluminum barrel lacks external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames without protruding hardware.
This specific configuration includes a SUS420J2 stainless steel rod (option A) for superior resistance to moisture and washdown chemicals. Equipped with a built-in magnet (option S), it supports AirTAC CMSE reed and DMSE electronic position sensors along the three integrated side grooves. Furthermore, the field-adjustable pneumatic cushioning at both ends allows technicians to fine-tune end-of-stroke deceleration, effectively softening hard impacts during high-speed operations.
Airtac SE80 Standard Cylinder SE80AX105S Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX105S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 105 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX105S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×105 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX105S Is Used
Case Erector Jaws
Provides the 2513 N push force required to fold and seal heavy corrugated cardboard flaps in high-speed packaging lines, benefiting from the adjustable cushion to prevent jaw slamming.
Press Brake Backgauge
Positions sheet metal accurately in a press brake backgauge system, where the SUS420J2 stainless rod resists coolant mist and the magnet enables DMSE electronic positioning.
Injection Mold Extractor
Drives robust robotic extractors that pull molded parts from injection machines, utilizing the 3518 N force at 0.7 MPa to reliably overcome mold release friction.
Is the Airtac SE80 Standard Cylinder SE80AX105S the Right Cylinder?
Selecting the SE80AX105S is optimal when your application requires roughly 2500 N of thrust at 0.5 MPa. If you need less force, stepping down to the 63 mm bore yields 1559 N of push, while moving up to the 100 mm bore provides 3927 N, allowing you to scale thrust precisely to your payload. Because this is a standard double-acting cylinder, it will drift if air pressure is lost or the valve is centered; applications requiring true load-holding must pair it with a BSE rod lock or an external pilot-operated check valve.
As a dimensionally interchangeable ISO 15552 cylinder, it serves as a drop-in replacement for other standard profile cylinders, utilizing the same mounting hardware and PT3/8 port. The 105 mm stroke falls below the 300 mm threshold where side-load bending becomes critical, but always ensure the rod-end thread (M20x1.5) aligns properly with your load to avoid undue bearing wear.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX105S FAQ
The SE80AX105S delivers a push force of 2513 N and a pull force of 2268 N at 0.5 MPa. At 0.7 MPa, the push force reaches 3518 N, with a maximum push capacity of 513 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, the SE80AX105S is dimensionally interchangeable per the ISO 15552 / VDMA 24562 standard. You can drop it in as a replacement using existing mounting brackets and PT3/8 port connections, provided your system pressure does not exceed 1.0 MPa.
