Airtac SE80 Standard Cylinder SE80X100
The AirTAC Airtac SE80 Standard Cylinder SE80X100 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 100mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke100 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80X100
The AirTAC SE80X100 is a double-acting, single-rod ISO 15552 profile cylinder engineered to deliver a robust 2513 N push force at 0.5 MPa. It features a square extruded aluminum barrel without external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames. This clean profile simplifies retrofitting into tight spaces while maintaining the standardized ISO 15552 mounting interface.
This 80 mm bore unit incorporates field-adjustable air cushioning at both ends, allowing technicians to tune end-of-stroke deceleration via a set screw to soften hard impacts during high-speed operations. Operating at 30-800 mm/s with a PT3/8 port and a Ø25 mm hard-chrome rod, it is built for heavy-duty cycling. Note that this specific SKU lacks a built-in magnet, so it does not support CMSE or DMSE position sensing without modification.
Airtac SE80 Standard Cylinder SE80X100 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80X100 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80X100
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80X100 Is Used
CNC Fixture Clamping
Secures heavy cast iron engine blocks during machining, utilizing the 2513 N push force to lock parts rigidly against locators.
Pallet Dispenser Pusher
Separates and indexes empty wooden pallets on a high-speed packaging line, using the 100 mm stroke to feed them into the loading zone.
Injection Mold Ejection
Drives the knockout plate to eject hardened plastic automotive interior panels from the mold cavity reliably.
Is the Airtac SE80 Standard Cylinder SE80X100 the Right Cylinder?
Selecting the SE80X100 makes sense when your application requires approximately 2513 N of push force at 0.5 MPa. If your load demands less energy, stepping down to the 63 mm bore yields a 1559 N push, conserving compressed air. Conversely, if you need more thrust, the 100 mm bore provides 3927 N. Because this is a standard double-acting cylinder, it will drift if air pressure is lost or the valve is centered; applications requiring true load-holding during power loss should utilize the BSE series rod lock instead. As a true ISO 15552 cylinder, it serves as a drop-in dimensional replacement for other ISO 15552 profile cylinders, sharing standard mounting hardware like FA front flanges or TC trunnions.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80X100 FAQ
At 0.5 MPa, the SE80X100 delivers 2513 N of push force and 2268 N of pull force. At 0.7 MPa, the push force increases to 3518 N. The maximum push force is 513 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, it is dimensionally interchangeable per ISO 15552, meaning it shares standard mounting footprints with other profile cylinders. However, because it is a standard double-acting cylinder, it cannot hold a load if air pressure drops; it will drift. For fail-safe holding, consider the BSE variant with a rod lock.
