Airtac SED Double Rod Cylinder SED100X130S
The AirTAC Airtac SED Double Rod Cylinder SED100X130S is a genuine double-acting ISO 15552 double-rod cylinder: a Ø25mm piston rod exits BOTH ends of the Ø100mm bore, giving equal force and speed in both directions and letting you mount tooling or a sensor flag on the back rod. Stroke 130mm, PT1/2 ports, adjustable cushioning.
- BoreØ100 mm
- Stroke130 mm
- Port sizePT1/2
- ConfigurationDouble rod
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SED Double Rod Cylinder SED100X130S
The AirTAC SED100X130S is a double-acting, double-rod ISO 15552 profile cylinder. A 25mm rod exits both end covers, yielding identical annulus areas. This design outputs an equal 3681 N of force in both directions at 0.5 MPa. The extruded aluminum barrel omits external tie rods, and the included -S magnet enables position tracking via CMSE reed or DMSE electronic sensors.
Because a rod protrudes from the rear cover, you can mount a cam or limit flag directly on it to trigger external switches. The cylinder provides field-adjustable air cushioning at both ends to decelerate heavy 100mm pistons near stroke limits. Remember to leave rear-rod clearance in your layout, as overall length exceeds a single-rod SE cylinder.
Airtac SED Double Rod Cylinder SED100X130S Technical Specifications
| Model | Airtac SED Double Rod Cylinder SED100X130S |
|---|---|
| Series | SED ISO 15552 double-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 130 mm |
| Configuration | Double rod, double acting |
| Port size | PT1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SED datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø100mm)
| Pressure | Force (both directions) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Because a rod exits both ends, the effective piston area — and therefore the force — is identical on extend and retract. Actual usable force is lower than theoretical; size with a safety margin.
Model Code: Airtac SED Double Rod Cylinder SED100X130S
| SED | ISO 15552 profile-barrel DOUBLE-ROD double-acting cylinder. |
|---|---|
| 100 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SED): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SE (single rod), SEJ (double-rod adjustable stroke), BSED (double-rod rod lock).
Where the Airtac SED Double Rod Cylinder SED100X130S Is Used
Servo Press Platen
Drives a 100mm press platen with 5153 N of equal both-way force, using the rear rod to mount a physical cam for mechanical limit signaling.
Pallet Divert Arm
Actuates a heavy divert arm on a packaging conveyor, leveraging twin rods to prevent binding and resist torsional side loads during part transfer.
Indexing Gate
Powers an automated factory indexing gate where the symmetrical 3681 N force at 0.5 MPa ensures consistent push and pull dynamics.
Is the Airtac SED Double Rod Cylinder SED100X130S the Right Cylinder?
Choose this 100mm bore if your mechanism needs 5153 N of thrust at 0.7 MPa in both travel directions. Stepping down to an 80mm SED drops the both-way force to 3175 N at 0.7 MPa, while stepping up to a 125mm SED raises it to 8028 N. The twin-rod architecture resists torsional load and guides against rotation better than a single rod, making it ideal for synchronized dual-side actuation.
When replacing an ISO 15552 unit, match the 100mm bore, 130mm stroke, PT1/2 port, and mounting interface (Basic, FA, LB, TC, FTC, TCM1, or TCM2). A plain SED does not hold position on air loss; the piston drifts. For fail-safe holding, use a BSED double-rod lock or an external pilot-operated check valve.
Quick checklist
- ✓ Equal force/speed both directions needed?
- ✓ Back-rod space for tooling or a flag
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Support both rod ends; avoid side load.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SED Double Rod Cylinder SED100X130S FAQ
Because a rod occupies both sides of the piston, force is identical in both directions. It provides 3681 N at 0.5 MPa, 5153 N at 0.7 MPa, and a maximum of 751 kgf at 1.0 MPa.
The twin rods offer superior anti-rotation guidance and allow you to mount tooling, a cam, or a DMSE sensor flag on the rear rod end. It is dimensionally interchangeable per ISO 15552 but requires rear-rod clearance.
