Airtac SED Double Rod Cylinder SED100X140S
The AirTAC Airtac SED Double Rod Cylinder SED100X140S is a genuine double-acting ISO 15552 double-rod cylinder: a Ø25mm piston rod exits BOTH ends of the Ø100mm bore, giving equal force and speed in both directions and letting you mount tooling or a sensor flag on the back rod. Stroke 140mm, PT1/2 ports, adjustable cushioning.
- BoreØ100 mm
- Stroke140 mm
- Port sizePT1/2
- ConfigurationDouble rod
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SED Double Rod Cylinder SED100X140S
The AirTAC SED100X140S is a double-acting, double-rod profile cylinder built to ISO 15552 dimensional standards. Because a Ø25 mm rod exits both end covers, the effective piston area is identical on extend and retract. This yields exactly 3681 N of output force at 0.5 MPa in both directions, ensuring perfectly balanced motion for heavy loads.
Equipped with a standard magnet (-S), this 100 mm bore unit supports CMSE reed and DMSE electronic sensors for end-of-stroke detection. The extruded aluminum barrel omits external tie rods, while adjustable air cushions at both ends allow you to tune deceleration for 140 mm strokes.
Airtac SED Double Rod Cylinder SED100X140S Technical Specifications
| Model | Airtac SED Double Rod Cylinder SED100X140S |
|---|---|
| Series | SED ISO 15552 double-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 140 mm |
| Configuration | Double rod, double acting |
| Port size | PT1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SED datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø100mm)
| Pressure | Force (both directions) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Because a rod exits both ends, the effective piston area — and therefore the force — is identical on extend and retract. Actual usable force is lower than theoretical; size with a safety margin.
Model Code: Airtac SED Double Rod Cylinder SED100X140S
| SED | ISO 15552 profile-barrel DOUBLE-ROD double-acting cylinder. |
|---|---|
| 100 | Bore size in mm. |
| ×140 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SED): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SE (single rod), SEJ (double-rod adjustable stroke), BSED (double-rod rod lock).
Where the Airtac SED Double Rod Cylinder SED100X140S Is Used
Servo Press Positioning
Drives a heavy stamping head with 3681 N of equal both-way force, using the twin rods to prevent chassis twist during high-tonnage press cycles.
Pallet Transfer Gate
Shifts a 100 mm bore diverter arm across a conveyor line, relying on the through-rod design to mount a cam flag for position confirmation.
Mold Clamping Fixture
Secures heavy injection molds with balanced 5153 N force at 0.7 MPa, leveraging the rigid double-rod guidance to keep halves perfectly aligned.
Is the Airtac SED Double Rod Cylinder SED100X140S the Right Cylinder?
Choose this 100 mm bore when you need substantial equal both-way thrust. If your application requires less force, stepping down to the 80 mm bore provides 2268 N at 0.5 MPa. If you need more power, the 125 mm bore offers 5734 N. The twin-rod design provides superior anti-rotation resistance compared to a single-rod SE cylinder, and the rear rod can drive a secondary mechanism or sensor flag.
For ISO 15552 drop-in replacements, match the 140 mm stroke, PT1/2 port, and preferred mounting from the SED subset (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that the air cushion only decelerates the load near stroke end; it does not hold position on air loss. For fail-safe holding, consider a BSED double-rod rod lock cylinder or an external locking device.
Quick checklist
- ✓ Equal force/speed both directions needed?
- ✓ Back-rod space for tooling or a flag
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Support both rod ends; avoid side load.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SED Double Rod Cylinder SED100X140S FAQ
Because the double-rod design subtracts rod area from both sides, force is equal in both directions: 3681 N at 0.5 MPa, 5153 N at 0.7 MPa, and a maximum of 751 kgf at 1.0 MPa.
The twin rods provide superior anti-rotation guidance and allow the rear rod to drive secondary tooling or sensors. It also makes the extend and retract forces perfectly identical, which is critical for precision balancing.
