Airtac SEJ Adjustable Cylinder SEJ32X100-75
2. Asymmetric bidirectional piston seal structure with compact dimensions and integrated oil reservoir function;
3. Rodless square aluminum tubing construction enhances corrosion resistance;
4. Adjustable cushioning mechanism ensures smooth stroke modulation;
5. Customizable configurations with multiple cylinder variants and mounting accessories;
6. High-temperature resistant sealing materials enable operational range of 0-150°C.
Category: Adjustable Cylinders | Brand: AirTAC | Series: SEJ
AirTAC SEJ Series Adjustable Cylinder SEJ32X100-75 Technical Specifications
- Model: SEJ32X100-75
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 100mm (adjustable from 0-100mm)
- Mounting spacing: 75mm (ISO 15552 standard)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: M5x0.8 (standard) / G1/8 optional
- Temperature range: -20℃ to 80℃
- Cylinder tube material: Aluminum alloy with hard anodized finish
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 1.65kg ±2%
- Dimensions (L×W×H): 198mm × 75mm × 40mm (retracted state)
- Rod end thread: M12×1.25
- Max theoretical thrust: 235N @0.63MPa
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if required)
Precision-engineered adjustable stroke cylinder featuring micrometer-style stroke adjustment with ±0.5mm repeatability. The dual magnetic switch slots (T-slot and U-slot) enable flexible sensor mounting. Integrated locknut design maintains stroke setting under vibration. Special wear-resistant guide rings ensure smooth operation at 0.1-1.5 m/s speeds.
- Precision positioning in automated assembly lines
- Clamping force adjustment in injection molding fixtures
- Variable height positioning for conveyor systems
- Packaging machine product ejection mechanisms
- Printing press paper feed adjustments
- Test equipment requiring programmable stroke changes
Installation notes:
Use M5 mounting screws with 22-25N·m torque. For vertical mounting,
install auto oiler upstream. Adjust cushion needle gradually - overtightening
may cause piston deformation. Maximum side load: 25N.
| Property | Property Value |
|---|---|
| sku | SEJ32X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
