AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X120-20S

The AirTAC SEJ Adjustable Cylinder SEJ32X120-20S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 20mm window, so this Ø32mm unit covers an effective stroke of 100–120mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke120 mm
  • Adjust window20 mm
  • Effective stroke100–120 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X120-20S

The AirTAC SEJ32X120-20S is a double-acting, double-rod ISO 15552 profile cylinder with a 20 mm adjustable stroke window, allowing you to dial the retract end from 100 to 120 mm. A rod exits both ends, ensuring the annulus area remains identical for equal force and speed in both directions.

This unit includes a magnet for CMSE or DMSE position sensing. It features field-adjustable air cushions at both ends to manage deceleration, and the back-rod stop screw lets you fine-tune the exact end position during machine commissioning before locking it down.

Airtac SEJ Adjustable Cylinder SEJ32X120-20S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X120-20S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke120 mm
Adjustment window20 mm (100–120 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 20mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X120-20S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×120Nominal stroke length in mm.
-20Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X120-20S Is Used

tune

Packaging Flap Folding

Dial in the 100-120 mm stroke range to fold varying cardboard flap heights precisely, utilizing the 345 N both-way force for consistent packaging line changeovers.

precision_manufacturing

Stop-Gate Positioning

Fine-tune the retract stop screw on a conveyor diverter gate to match part widths perfectly during commissioning without swapping out cylinder hardware.

science

Lab Dispenser Calibration

Adjust the end position to calibrate exact fluid dispense volumes, relying on the equal extend and retract speeds for repeatable test cycles.

Is the Airtac SEJ Adjustable Cylinder SEJ32X120-20S the Right Cylinder?

Confirm the 20 mm adjustment window covers your required 100-120 mm end-position range. If you need less force, there is no smaller SEJ bore, but if you need more thrust, stepping up to the 40 mm bore provides 528 N at 0.5 MPa each way. If your application never requires stroke changes, a fixed-stroke SED cylinder is sufficient.

For ISO 15552 replacements, match the 32 mm bore, 120 mm stroke, PT1/8 port, and your mounting choice from Basic, FA, LB, TC, FTC, TCM1, or TCM2. Note that the adjustable cushion decelerates the load near stroke end but does not hold position on air loss; for fail-safe holding, use an external rod lock. At 120 mm stroke, side loads are minimal, but always ensure linear guidance for optimal seal life.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (20mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 20mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X120-20S FAQ

A stop screw on the back rod lets you mechanically shorten the retract stroke over a 20 mm window. The effective stroke range is 100 to 120 mm, which you set and lock during machine commissioning.

Because the rod exits both ends, force is identical in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
