Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10
The AirTAC Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10 is a genuine double acting, adjustable stroke ISO 15552 (orig. ISO 6431) tie-rod air cylinder with a Ø125mm bore and 100mm stroke, G1/2 air ports and adjustable end cushioning. Its large-bore tie-rod build delivers high thrust and drops into standardized ISO 15552 mounting on heavy automation.
- BoreØ125 mm
- Stroke100 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM27×2.0
- CushionAdjustable, 40 mm
About the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10
Delivering 6136 N of push force at 0.5 MPa, this large-bore ISO 15552 tie-rod cylinder handles serious work. It provides a safe working load of about 3682 N, which means you can vertically lift roughly 313 kg with a 2:1 safety margin. The G1/2 port and four steel tie rods clamping the aluminum barrel ensure rigid, reliable operation.
The external adjuster lets you shorten the extend stroke on-site by up to 10 mm, giving a usable range of 90 to 100 mm without changing the cylinder itself. This on-site end-position tuning is paired with a two-way piston seal and adjustable air cushions at both ends. Note that this specific SKU lacks a magnet, so it cannot take a magnetic sensor; you would need the -S variant for CMSG/DMSG/EMSG switches.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10 Technical Specifications
| Model | Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10 |
|---|---|
| Series | SGC ISO 15552 tie-rod cylinder |
| Bore size | Ø125 mm |
| Stroke | 100 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SGC datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Thread options: PT (blank) / G. TPU seals are not available for the Ø250 bore (NBR / Viton only).
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10
| SGCJ | ISO 15552 tie-rod cylinder (adjustable-stroke type). |
|---|---|
| 125 | Bore size in mm (125 / 160 / 200 / 250). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
SGC-family variants: SGC (double acting), SGCD (double rod), SGCJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / FTC / TCM1 / TCM2. Seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10 Is Used
Press Fit Tuning
Fine-tune the 10 mm extend window on-site to set the exact bottoming position for pressing bearings without swapping the physical cylinder.
Transfer Diverter
Adjust the extend stop to perfectly align a diverter gate profile for varying product sizes on a heavy-duty packaging line.
Pallet Stopper
Use the 6136 N push force to halt heavy pallets, tweaking the 10 mm stroke window to accommodate different pallet thicknesses.
Is the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10 the Right Cylinder?
When sizing this 125 mm bore against its neighbors, it sits at the lower edge of the large-bore family, offering 6136 N push at 0.5 MPa compared to the 10053 N available from the 160 mm bore. The adjustable stroke feature is particularly useful when you want a shared spare across slight stroke variants or need fine end-position tuning on the machine. Mounting options include FA, LB, TC, FTC, TCM1, and TCM2. Because this unit has no -S suffix, it cannot accept position sensors. For any stroke over 500 mm, always use a guide to prevent side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Long-stroke side load — support the rod end
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load; support long strokes at the rod end.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10 FAQ
This 125 mm bore cylinder features a G1/2 port and delivers 6136 N push / 5734 N pull at 0.5 MPa, 8590 N push / 8028 N pull at 0.7 MPa, and a theoretical maximum of 1251 kgf at 1.0 MPa.
The nominal 100 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 10 mm, giving a usable extend range of 90 to 100 mm. The retract end remains fixed.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Made to Order
Large-bore cylinders built to order — confirm lead time.
Fast Reply
Most inquiries answered within 7-8 hours.
