Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S
The AirTAC Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S is a genuine double acting, adjustable stroke ISO 15552 (orig. ISO 6431) tie-rod air cylinder with a Ø125mm bore and 100mm stroke, G1/2 air ports and adjustable end cushioning. Its large-bore tie-rod build delivers high thrust and drops into standardized ISO 15552 mounting on heavy automation.
- BoreØ125 mm
- Stroke100 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM27×2.0
- CushionAdjustable, 40 mm
About the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S
Delivering 6136 N of push force at 0.5 MPa, this large-bore ISO 15552 tie-rod cylinder uses four steel rods to clamp its aluminum barrel for high structural rigidity. A built-in piston magnet supports CMSG, DMSG and EMSG switches for precise position detection, while the G1/2 port handles the 30-500 mm/s speed range.
The external adjuster allows you to shorten the extend stroke on-site by up to 10 mm, giving a usable range of 90-100 mm without changing the cylinder itself. This on-site fine-tuning is ideal for shared spares across stroke variants. It handles a safe working load of about 3682 N, which translates to lifting roughly 313 kg vertically with a 2:1 margin.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S Technical Specifications
| Model | Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S |
|---|---|
| Series | SGC ISO 15552 tie-rod cylinder |
| Bore size | Ø125 mm |
| Stroke | 100 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SGC datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Thread options: PT (blank) / G. TPU seals are not available for the Ø250 bore (NBR / Viton only).
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S
| SGCJ | ISO 15552 tie-rod cylinder (adjustable-stroke type). |
|---|---|
| 125 | Bore size in mm (125 / 160 / 200 / 250). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
SGC-family variants: SGC (double acting), SGCD (double rod), SGCJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / FTC / TCM1 / TCM2. Seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S Is Used
Press Fit Tuning
Use the 10 mm extend-shortening window to dial in the exact bottoming position of a press fit without remachining stops.
Divertor Gate Adjustment
Fine-tune the actuation reach on a conveyor sorting gate on-site to accommodate different package widths.
Shared Spare Actuator
Stock one cylinder and adjust the extend stroke down 10 mm to cover multiple 90-100 mm positioning tasks.
Is the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S the Right Cylinder?
When sizing this 125 mm bore unit, stepping down is not an option as it is the low edge of the SGCJ range, producing 6136 N push at 0.5 MPa. Stepping up to the 160 mm bore yields 10053 N push if your application outgrows this capacity. The adjustable stroke helps when you need to tune the end position on-site or want a shared spare across slightly different stroke variants. Mounting options include FA, LB, TC, FTC, TCM1 and TCM2. The included -S magnet enables CMSG/DMSG/EMSG sensor use. Since the stroke is only 100 mm, side-load guide requirements are minimal compared to long-stroke installations.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Long-stroke side load — support the rod end
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load; support long strokes at the rod end.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-10S FAQ
At 0.5 MPa it provides 6136 N push and 5734 N pull. At 0.7 MPa it provides 8590 N push and 8028 N pull. The theoretical maximum force is 1251 kgf at 1.0 MPa. The air port size is G1/2.
The nominal 100 mm stroke is the maximum. The external stop screw lets you shorten the extend stroke on-site by up to 10 mm, yielding a usable extend range of 90-100 mm. The retract end is fixed. This mechanism only sets the end position; it does not lock the load.
