Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50
The AirTAC Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50 is a genuine double acting, adjustable stroke ISO 15552 (orig. ISO 6431) tie-rod air cylinder with a Ø125mm bore and 100mm stroke, G1/2 air ports and adjustable end cushioning. Its large-bore tie-rod build delivers high thrust and drops into standardized ISO 15552 mounting on heavy automation.
- BoreØ125 mm
- Stroke100 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM27×2.0
- CushionAdjustable, 40 mm
About the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50
Delivering 6136 N of push force at 0.5 MPa, this large-bore ISO 15552 tie-rod cylinder uses four steel rods to clamp its aluminium barrel for high structural rigidity. The G1/2 port feeds a double-acting single-rod piston that runs at 30-500 mm/s. It handles a safe working load of roughly 3682 N, which means you can vertically lift about 313 kg with a 2:1 safety margin.
The -50 code defines a 50 mm external adjuster window, letting you shorten the extend stroke on-site from the 100 mm maximum down to 50 mm without changing the cylinder body. The retract end remains fixed. A two-way piston seal minimizes leakage, and the standard TPU elastomer handles -20 to +70 C, though a Viton H option extends this to 150 C.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50 Technical Specifications
| Model | Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50 |
|---|---|
| Series | SGC ISO 15552 tie-rod cylinder |
| Bore size | Ø125 mm |
| Stroke | 100 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SGC datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Thread options: PT (blank) / G. TPU seals are not available for the Ø250 bore (NBR / Viton only).
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50
| SGCJ | ISO 15552 tie-rod cylinder (adjustable-stroke type). |
|---|---|
| 125 | Bore size in mm (125 / 160 / 200 / 250). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
SGC-family variants: SGC (double acting), SGCD (double rod), SGCJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / FTC / TCM1 / TCM2. Seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50 Is Used
Press Fit Tuning
Dial in the exact 50 to 100 mm extend position on-site for inserting bearings without swapping the cylinder.
Transfer Diverter
Adjust the extend stop to route different package sizes on a belt line using the 6136 N push force.
Pallet Stop Gate
Fine-tune the gate extension distance on-site to handle varying pallet widths securely.
Is the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50 the Right Cylinder?
This 125 mm bore sits at the low edge of the SGCJ range, stepping up from smaller units to provide 6136 N push at 0.5 MPa; if you need significantly more power, the 160 mm bore offers 10053 N. The adjustable stroke is ideal for sharing one spare across machines that need slightly different extend end-positions. Mounting options include FA, LB, TC, FTC, TCM1 and TCM2 brackets. Because this specific SKU lacks the -S suffix, it cannot accept CMSG/DMSG/EMSG magnetic sensors. Even at 100 mm stroke, always use a guide to prevent side-load wear.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Long-stroke side load — support the rod end
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load; support long strokes at the rod end.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-50 FAQ
At 0.5 MPa it provides 6136 N push and 5734 N pull. At 0.7 MPa it yields 8590 N push and 8028 N pull. The theoretical maximum force is 1251 kgf at 1.0 MPa.
The 100 mm nominal stroke is the maximum. The external -50 adjuster lets you shorten the extend stroke on-site by up to 50 mm, giving a usable extend range of 50 to 100 mm. The retract end is fixed, and the adjuster only sets end position, not load holding.
