Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20
The AirTAC Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20 is a genuine double acting, adjustable stroke ISO 15552 (orig. ISO 6431) tie-rod air cylinder with a Ø125mm bore and 1000mm stroke, G1/2 air ports and adjustable end cushioning. Its large-bore tie-rod build delivers high thrust and drops into standardized ISO 15552 mounting on heavy automation.
- BoreØ125 mm
- Stroke1000 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM27×2.0
- CushionAdjustable, 40 mm
About the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20
Delivering 6136 N of push force at 0.5 MPa, this ISO 15552 tie-rod cylinder brings four steel rods clamping an aluminum barrel for heavy-duty rigidity. The G1/2 port feeds a 32 mm rod running on a two-way piston seal, yielding a safe working load around 3682 N, which translates to lifting about 313 kg vertically with a 2:1 margin.
The -20 code gives an external adjuster that shortens the extend stroke on-site by up to 20 mm, letting you fine-tune the end position across a 980 to 1000 mm window without swapping the cylinder. Standard TPU seals handle -20 to +70 C, while a Viton H option raises that to 150 C. Because this SKU lacks a -S suffix, it cannot accept CMSG or DMSG magnetic sensors.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20 Technical Specifications
| Model | Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20 |
|---|---|
| Series | SGC ISO 15552 tie-rod cylinder |
| Bore size | Ø125 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SGC datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Thread options: PT (blank) / G. TPU seals are not available for the Ø250 bore (NBR / Viton only).
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20
| SGCJ | ISO 15552 tie-rod cylinder (adjustable-stroke type). |
|---|---|
| 125 | Bore size in mm (125 / 160 / 200 / 250). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
SGC-family variants: SGC (double acting), SGCD (double rod), SGCJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / FTC / TCM1 / TCM2. Seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20 Is Used
Press Stroke Calibration
Dial in the exact 980 to 1000 mm extend end-position on-site to accommodate varying material thicknesses without changing the cylinder mounting.
Heavy Pallet Positioning
Shift heavy loads using the 8590 N push force at 0.7 MPa, relying on the 40 mm adjustable air cushions to decelerate the 1-meter travel safely.
Long-Reach Material Descending
Lower assemblies over a 1000 mm drop with a safe vertical lift capacity near 313 kg, ensuring smooth stops via the tie-rod construction.
Is the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20 the Right Cylinder?
Size this 125 mm bore against its neighbors: step down to save air if 5734 N pull at 0.5 MPa is excessive, or step up to a 160 mm bore if you need over 10053 N. The -20 mm adjustable window is ideal for sharing one spare across multiple stroke variants or dialing in end positions on-site. Mount via FA, LB, TC, FTC, TCM1, or TCM2 brackets. At 1000 mm, long-stroke rod-bending is a real risk, so use an external guide to prevent side loads. Note that a plain cylinder drifts on air loss, so fit an external rod lock for held loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Long-stroke side load — support the rod end
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load; support long strokes at the rod end.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-20 FAQ
This 125 mm bore cylinder features a G1/2 port and delivers 6136 N push and 5734 N pull at 0.5 MPa. At 0.7 MPa it yields 8590 N push and 8028 N pull. The theoretical maximum force is 1251 kgf at 1.0 MPa.
The 1000 mm nominal stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 20 mm, giving a usable extend range of 980 to 1000 mm. The retract end is fixed, and this stop is for positioning only, not load holding.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Made to Order
Large-bore cylinders built to order — confirm lead time.
Fast Reply
Most inquiries answered within 7-8 hours.
